PD-6807U/6807R
Package Contents
7” -Mount Rear Customer Display
with Bracket (x 1)
3- -Tapping Screw (x 4) 10L Self
USB Cable -6807U (x 1) for PD
RS-232 Cable for PD-6807R (x 1)
User Manual (x 1)
Product Features
OPOS application support
7” graphical cus line dtomer isplay
TFT LCD panel with resolution up to 800 x 480
Adjustable font and background color
JPEG graphics display support
Support 13 c p to ode ages, each having 128 characters
Support , each having to 12 international character sets 12 characters
S show and slide creen s support aver
Command emulations support: ADM, Aedex, ESC/POS, Futaba,
Noritake, UTC
Powered through the USB or COM port
Virtual COM port supported for USB interface
R -mount for -3000 ear PS series terminal
PD- U6807 /6807R
R - ear Mount Customer Display
User Manual
19520905020 Ver. A0
1
Views of the PD-6807U/PD6807R
Front View
Rear View
Bottom View -6807Uof PD
Bottom View -6807Rof PD
Screw Holes
TFT LCD P anel
USB Port
DC- IN Power Jack
(Reserved)
USB Port
RJ45 Port
2
Mounting the Mount Display Rear- onto a POS Terminal
This section provides -by-step step instructions to assist you in installing
PD POS terminal.-6807U/6807R -3000 series to PS a reminder, As
please ensure that your POS terminal is completely shut down before
proceeding with installation of -6807U/6807R. PD
1. Remove the rear I/O cover of your
PS-3000 series POS terminal.
2. Insert the USB or cable into the POS terminal.RS-232
For PD-6807U model, align the A type connector of the USB
cable with the USB port of your POS -6807R terminal; for PD
model, have -232 cable the RJ50 connector of RS with a label
describing “To Host” attached to RJ50 port of the POS terminal.
PD- 6807U
PD- R 6807
3. Align the four screw holes of the
customer display bracket with the four
screw holes on the rear side of the POS
terminal.
Align
To Host
3
