Sida 1/4
USER MANUAL
Label Rewinder for
Primera label printers
this product is certified:
510752-081320
APPLICATION
The rewinder is used to rewind the labels on roll having xed 3” internal diameter. The maximum
external roll diameter allowed is up to 250 mm (10”) while the maximum label width is up to
220 mm (8.66”).
POWER SUPPLY
An external power supply 100/240VAC - 2.5A at 24V allows an electronic circuit to provide,
through the tension arm, the speed and sense of rotation auto adjustment.
FUNCTIONING
The printer must be put onto the rewinder’s printer plate, in this way the correct rewinding
operations are guaranteed and also the device is fastened to the printer.
The rewinder has two types of speed adjustments, through the two buttons it is possible to set
the maximum speed required while the tension arm will auto adjust the speed from zero to the
set value and the sense of rotation.
WORKING CONDITIONS
- When the printer forwards the media for printing, the tension arm goes down, the device rewinds
the media. Yellow or green led on depending on the selected rewinding mode (face-in or face-out).
- When the tension arm is in the middle position, the device is idle. Both yellow and green leds on.
- When the printer backwards the media, the tension arm goes up, the device unwinds it. Yellow
or green led on depending on the selected rewinding mode (face-in or face-out).
When the unit is operating but the media is not loaded or it runs out, the tension arm reaches
the lowest position and after few seconds the unit will stop by itself, both leds blink and it beeps.
CONTROL PANEL
ON-OFF
Push this button to turn On or O the unit.
INCREASE SPEED
Push this button to increase the rotation speed.
DECREASE SPEED
Push this button to decrease the rotation speed.
LABEL FACE-OUT
Turn the unit o. Keep pushed “FACE OUT” button, push and
release “ON-OFF” button while the green led turns on and o.
The unit is now ready to operate.
LABEL FACE-IN
Turn the unit o. Keep pushed “FACE IN” button, push and
release “ON-OFF” button while the yellow led turns on and o.
The unit is now ready to operate.
