CLEANING & MAINTENANCE

For any cleaning and maintenance, switch o and unplug the washing machine.

Do not use ammable uids to clean the washing machine.

CLEANING THE OUTSIDE OF THE WASHING MACHINE

Use a soft damp cloth to clean the outer parts of the washing

machine.

Do not use glass or general purpose cleaners, scouring

powder or similar to clean the control panel – these

substances might damage the printing.

CHECKING THE WATER SUPPLY HOSE

Check the inlet hose regularly for brittleness and cracks. If

damaged, replace it by a new hose available through our

After-Sales Service or your specialist dealer.

Depending on the hose type:

If the inlet hose has a transparent coating, periodically check

if the colour intensies locally. If yes, the hose may have a leak

and should be replaced.

For water stop hoses: check the small safety valve inspection

window (see arrow). If it is red, the water stop function was

triggered, and the hose must be replaced by a new one.

For unscrewing this hose, press the release button (if

available) while unscrewing the hose.

CLEANING THE MESH FILTERS IN THE WATER SUPPLY HOSE

1. Close water tap and unscrew the inlet hose.

2. Clean the mesh lter at the hose’s end carefully with a

ne brush.

3. Now unscrew the inlet hose on the back of the washing

machine by hand. Pull out the mesh lter from the valve

on the back of the washing machine with pliers and

carefully clean it.

4. Insert the mesh lter again. Connect the inlet hose to

water tap and washing machine again. Do not use a tool

to connect the inlet hose. Open the water tap and check

that all connections are tight.

CLEANING THE DETERGENT DISPENSER

CLEANING THE WATER FILTER / DRAINING RESIDUAL WATER

Switch o and unplug the washing machine before cleaning the water lter or draining residual water. If you used a hot

wash programme, wait until the water has cooled down before draining any water.

Clean the water lter regularly, to avoid that the water cannot drain after the wash due to obstruction of the lter.

If the water cannot drain, the display indicates that the water lter may be clogged.

1. Remove the kick panel: Using a screwdriver, do that which

is shown in the following gure.

2. Container for the drained water:

Place a low and wide container under the water lter in

order to collect the residual water.

3. Drain the water:

Slowly turn the lter counter-clockwise until all the water

has come out. Allow the water to ow out without

removing the lter. Once the container is full, close the

water lter by turning it clockwise. Empty the container.

Repeat the procedure until all the water has been drained.

4. Remove lter: Lay a cotton cloth beneath the water lter,

which can absorb a small amount of rest water. Then

remove the water lter by turning it out anticlockwise.

5. Clean the water lter: remove residues in the lter and

clean it under running water.

6. Insert the water lter and reinstall the plinth: Reinsert the water

lter again by turning it in clockwise direction. Make sure to turn

it in as far as it goes; the lter handle must be in vertical position.

To test water tightness of the water lter, you can pour about 1

liter of water into the detergent dispenser. Then reinstall the

plinth.

Remove the dispenser by raising it and pulling it out (see gure).

Wash it under running water; this operation should be repeated frequently.

TRANSPORT AND HANDLING

Never lift the washing machine by holding it at the worktop.

1. Pull out the mains plug, and close the water tap.

2. Make sure that door and detergent dispenser are properly

closed.

3. Disconnect the inlet hose from the water tap, and remove

the drain hose from your draining point. Remove all rest

water from the hoses, and x them so that they cannot get

damaged during transport.

4. Ret the transport bolts. Follow the instructions for

removing the transport bolts in the “Installation Guide” in

reverse order.

Important: Do not transport the washing machine without

having xed the transport bolts.

AFTER-SALES SERVICE

BEFORE CALLING THE AFTER-SALES SERVICE

1. See if you can solve the problem by yourself with the help

of the suggestions given in the TROUBLESHOOTING

2. Switch the appliance o and back on again to see if the

fault persists.

IF AFTER THE ABOVE CHECKS THE FAULT STILL

OCCURS, GET IN TOUCH WITH THE NEAREST

AFTER-SALES SERVICE

To receive assistance, call the number shown on the warranty

booklet.

When contacting our Client After sales service, always specify:

• a brief description of the fault;

• the type and exact model of the appliance;

xxxxxxxxxxxx

• the service number (number after the word Service on the

rating plate).

• your full address;

• your telephone number.

If any repairs are required, please contact an authorised after-

sales service (to guarantee that original spare parts will be used

and repairs carried out correctly).
