INSTRUCTIONS FOR USE

Pro-Ject Bluetooth Box E

Dear music lover,

thank you for purchasing a P -Ject Audio Systems Bluetooth Box E. ro

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the

voltage in your area meets the voltage requirements printed on the power supply.

The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily

accessible at all times. Never handle the device, the power supply while your hands are wet or damp.

Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,

such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.

Never place any naked flame sources, such as lighted candles on or near the device. The product shall not

be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.

Connectors

Make all connections whilst the product is disconnected from the power supply.

Take care to connect the left and right channels correctly. The right channel is usually marked red,

the left channel black or white.

Never use any other power supply than the one supplied with the unit.

Never connect or disconnect power supply to or from the unit whilst the power supply is connected to

the mains.

Connection to the amplifier

Connect the socket to a line input (such as ) on your amplifier. Alternatively you can use

Anal

AnalAnalog

og og O

OOut

utut AUX

AUX

AUXAUX

also digital to connect the unit to a D/A converter or to digital input of your amplifier or AVR.

Optical

Optical Optical O

OOut

utut

Only one output is active at a time, use the small switch to select digital or analogue output.

Mains power connection

Connect the low voltage plug from the power supply to the socket before connecting the power

Power

PowerPower 9V DC

9V DC

9V DC 9V DC

supply to the mains.

Bluetooth pairing

Pairing with devices with Android OS

Open and tap on Turn on Bluetooth and tap on Searched devices will show up.

Settings

SettingsSettings Bluet

Bluet

BluetBluetooth

ooth

oothooth.

. . Sca

Sca

ScaScan

nn.

. .

Tap on (Confirm pairing code if requested). Once paired it will show "Connected to media

"B"BT

T T Box

Box

Box Box E

EE"

" "

Audio", now you can play music from your Android device over Bluetooth to Bluetooth Box E.

Pairing with Apple devices

Tap on tap on , turn on Bluetooth, your device will automatically start searching for

Sett

SettSettings

ings

ingsings,

, , Bluet

Bluet

BluetBluetooth

ooth

oothooth

available devices. Tap on " " and it will be connected to the Bluetooth Box E. Now you can play

BBT

T T Box

Box

BoxBox

music.

It´s possible to use Bluetooth Box E also with other than above mentioned devices, pairing procedure

is always similar.

Reconnecting

If you move out of range or turn off Bluetooth, Bluetooth Box E will disconnect from your device. To

reconnect simply open the Bluetooth manager and tap on "BT Box E". If the signal is lost for only a few

seconds it can reconnect automatically - typically if you move out of the range and then return back.

Adding a new phone or tablet

The unit can play music from one device at a time, but it is capable of being paired to up to 8 devices. If you

want to switch from one device to another, you have to disconnect existing connection to Bluetooth Box E

and then follow the steps for pairing with new device.

Troubleshooting

No music from speakers:

- make sure the Bluetooth Box E is powered

- make sure an audio cable or an optical cable is correctly connected to Bluetooth Box E

- make sure you are within the range

- make sure the Bluetooth is enabled and the device is connected to Bluetooth Box E. Volume level is

properly set
