Sida 1/9

INSTRUCTIONS FOR USE

Pro-Ject Debut III/Phono USB

30 5

PRO-JECT DEBUT III/PHONO USB

Controls, features and connections

1 Motor transportation screw (marked red)

2 Stepped drive pulley

3 Drive belt * 3a Hook *

4 Hub

5 Platter with felt mat *

6 Tonearm counterweight * 6a Downforce scale

7 Tonearm lift lever

8/18 Tonearm rest and removable transport lock

9 Tonearm tube 9a Tonearm base

10 Lid *

11 Lid hinges

12 Hinge fasteners

13 Power supply socket

14 Phono output sockets, earth connection and USB-out

15 Anti-skating weight adjustment scale

16 Anti-skating weight *

17 Anti-skating weight support hoop

20 Power switch

21 Headshell with finger lift and fitted Ortofon OM 5E cartridge

22 Motor

23 Single adapter *

24 3,5mm connector *

Power supply (not shown) *

Dear music lover,

thank you for purchasing a PRO-JECT AUDIO record player.

In order to achieve maximum performance and reliability with this record player you should study these instructions

for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

** Your turntable has been delivered with a factory fitted and adjusted cartridge, please ignore the

cartridge set up instructions unless changing the cartridge at a later date.

During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable

receptacle. Before starting assembly make yourself acquainted with the parts listed above and correspondingly

numbered in the technical drawings above. Separately packed items are marked with an asterisk *.

Set-up

Make sure the surface you wish to use the turntable on is level (use a spirit level) before placing the turntable on it.

Remove the two red transport screws (1) which secure the motor (22) during transportation.

Remove the transport lock (18) from the tonearm. Store it together with the two red motor transport screws

(1) in the original packaging so they are available for any future transportation.

Fit the drive belt (3) around the hub (4) and the smaller diameter part of the motor pulley (2). Avoid getting

sweat or grease on the belt as these will deteriorate the performance and reduce the belt's lifespan. Use

absorbent kitchen paper to remove any oil or grease from the outer edge of the hub and the belt. Fit the

platter (5) and felt mat over the spindle of the hub (4).

Produktspecifikationer

Varumärke:	Pro-Ject
Kategori:	DJ-utrustning
Modell:	Debut III
Vikt:	5500 g
Snabbstartsguide:	Ja
Produktmått (B x H x D):	415 x 118 x 320 mm
Produktens färg:	Svart
Strömförbrukning (vanlig):	2 W
Plug & Play-kompatibel:	Ja
Signal/brusförhållande (SNR):	-65 dB
AC-adapter, inspänning:	100 - 110 V
AC-adapter, frekvens:	50 - 60 hz
Damskydd medföljer:	Ja
Diameter, skivtallrik:	280 mm
Platter vikt:	1300 g
Produktstorlek, öppen (B x D x H):	415 x 405 x 365 mm
