Debut PRO S
Balanc
Setup Guide
Getting started:
•
Make sure to have enough space to
•
Always unpack and set up in a clean
•
Please Do
NOT
throw away the pac
service or want to return your prod
in the original packaging including
damage due to alternative packagi
guarantee a full refund.
•
complete manual:
www.project-audio.com/en/produc
1
Unpack all items from accessory bag:
Remove dust cover carton from the box.
Lift the wrapped turntable out of the box.
a) Anti Skating Weight
b) Flat belt (33 RPM) and round belt (78 RPM)
c) Adapter for 7“ singles / Allen keys
d) Connect it E RCA cable
e) Gauge for tracking force setting
f) Cartridge alignment protractor
Carefully remove the protective cover.
3
4
2
5
Unpack power supply, record puck and
counterweight from the bottom inserts.
Unpack the platter.
If necessary, level the turntable by
adjusting the feet.
68
7
Put the drive belt (b) on the pulley at
and sub-platter.
9
Put the platter on the turntable.
The turntable should always be placed on
a at surface. Check with a spirit level*.
Large pulley for round belt (78 RPM)
Screw the counterweight in place.
Put the gauge (e) on the platter.
10
11
12
13
Remove tonearm twist tie.
Lower the tonearm with the lift.
16
Put the loop of the Anti Skating Weight (a)
in the outer notch on the tonearm post.
Place the stylus on the gauge, so your
stylus sits on the point marked “23”.
14
17
15
Balance the tonearm by turning the counter-
weight forwards and backwards on the rod.
When the gauge stays level, your
tracking force is set correctly.
0°
Plug in power supply and Connect it E (e).
Yellow marks should be at the ampli er end.
18
19
Install the dustcover.
Connect to your hi -system and
have fun with music!
21
20
Use the rocker-switch on the bottom
left to select the playback speed.
33 RPM
RIGHT:
45 RPM / 78 RPM
STANDBY
MIDDLE:
LEFT:
*a spirit level can be purchased separately
a)
b) c)
d)
e)
f)
