INSTRUCTIONS FOR USE

Pro-Ject Essential III Flexi-Range

Dear Music Lover,

Congratulations and thank you for choosing Pro-Ject Audio Systems record player.

Your Essential III turntable has been handcrafted and rigorously tested by skilled technicians to give

you years of enjoyable, trouble free service.

Please contact your dealer if you require additional assistance.

Important:

Your turntable was shipped partially disassembled in order to avoid damage to sensitive parts.

Please check immediately to make sure that neither the packaging nor the device was damaged in

transit. If you are missing parts or if the unit is damaged, please do not operate and contact your

dealer.

Contents

Product illustrations 4

General setup

1. Platter and drive belt installation 5

2. Cartridge installation, stylus exchange 5

3. Vertical Tracking Force setting (VTF) 5-6

4. Anti-skating force adjustment 6

5. Azimuth setting 6

6. Turntable types and their functions 7

a) ESSENTIAL III 7

b) ESSENTIAL III BLUETOOTH 8

c) ESSENTIAL III PHONO 9

d) ESSENTIAL III SB 10

e) ESSENTIAL III DIGITAL 11-12

f) ESSENTIAL III RECORDMASTER 12-13

Technical parameters 14

Troubleshooting, warranty, service 15

Exploded view of the packaging 16

Please do your part to help protect the environment:

Disposal of packaging material:

Pro-Ject packaging is carefully designed to protect your component from damage in transit

and you

are strongly urged to keep the original packaging in order to safely ship or

otherwise transport your

turntable in the future.

However, the packaging materials were chosen to be environmentally friendly, so if

you must discard

the packaging, please recycle.

ESSENTIAL III FLEXI-RANGE

GENERAL INFORMATIONS

Controls, features and connections

1 PLATTER & FELT MAT

2 DRIVE PULLEY

3 DRIVE BELT

4 TONEARM COUNTERWEIGHT (4a) DOWNFORCE SCALE

5 TONEARM LIFT LEVER

6 TONEARM REST (66) REMOVABLE TRANSPORT LOCK

7 TONEARM TUBE

8 HEADSHELL WITH FINGER LIFT AND PRE-MOUNTED ORTOFON OM10

9 ANTI-SKATING WEIGHT WITH WIRE

10 ANTI-SKATING WEIGHT SUPPORT HOOP

11 ANTI-SKATING STUB WITH ADJUSTMENT SCALE

12 LID

13 LID HINGES

14 HINGE FASTENERS

15 POWER SUPPLY SOCKET

Accessories

1 ANTI-SKATING WEIGHT

2 HOOK TOOL FOR SPEED CHANGE

3 SINGLE ADAPTOR

4 ALLEN KEY 1,5mm

5 COUNTERWEIGHT no. 00

6 TWO-POINT CARTRIDGE ALIGNMENT PROTRACTOR

7 UNIVERSAL POWER SUPPLY

8 CONNECTION CABLE (CONNECT IT E RCA)

9 INSTRUCTION FOR USE

SETUP

1. Platter and drive belt installation

Please remove brown paper insert which holds the platter in transport position. Put the felt mat on the

top of the platter. Install the drive belt as shown in the following illustration.

2. Cartridge installation, stylus exchange

* If you purchased this turntable in a package that included the cartridge, this has already been done

for you.

Install the cartridge into the aluminium headshell, using the appropriate hardware included with your

cartridge. All cartridges with half inch mounting holes can be fitted.

Connect the cartridge as indicated below:

• White left channel L+

• Red right channel R+

• Green right channel R-

• Blue left channel L-

For correct cartridge alignment, use the two-point cartridge alignment protractor provided with your

Essential III accessories. If unfamiliar with two-point setup, please refer to your dealer.

A damaged or worn stylus may harm your record collection and should be replaced.

Please remove stylus protection before pulling the stylus from the cartridge and replace for a new one.

Stylus type is exchange for pre-mounted cartridge Ortofon OM 10: Stylus OM 10. If in doubt, consult your

local dealer or distributor.

3. Vertical Tracking Force setting (VTF)

Before setting the Vertical Tracking Force, confirm the exact weight of your cartridge. The

counterweight supplied (no. ) is suitable for cartridges from 3,5 to 5,5g. An alternative 00

counterweight (no. ) for cartridges between 6 – 9g is available on request. 01

Pushing carefully, turn the counterweight onto the rear end of the tonearm tube. With the tonearm lift

in lower position, carefully rotate the counterweight until the tonearm tube balances out. Once the

tonearm is correctly balanced, return it to the rest. Hold the counterweight without moving it, and gently

revolve the downforce scale ring until the zero is in line with the anti-skating stub.

Rotate the counterweight counter clockwise (seen from the front) to adjust the downforce according to the

cartridge manufacturer's recommendations. One mark on the scale represents 1 mN (= 0,1g / 0,1 Pond)

of downforce.

Please note: Adjust the VTF prior to installing the anti-skating weight.

4. Anti-skating force adjustment

Hang the loop of the thread of the anti-skating weight in the groove of the anti-skating stub

corresponding to the downforce applied to your cartridge and feed the thread through the loop of the

wire support.

The anti-skating force must be adjusted corresponding to the downforce as follows:

VTF Groove in the stub

10 - 14mN 1

from bearing rings

15 - 19mN 2

" " "

20mN and bigger

" " "

5. Azimuth setting

The cartridge needle must be perpendicular to the record in order to trace the groove wall

modulations correctly.

The azimuth (angle) is precisely set by the factory. In the event that you need to modify this setting,

however, follow the instructions below.

Loosen the small azimuth screw, again using the 1.5 mm allen key.

DO NOT REMOVE THE AZIMUTH SET SCREW COMPLETELY!

Loosen the screw just enough to be able to gently rotate the arm tube and set the azimuth to the

correct position. The correct position can be checked from the front view, preferably with the needle

placed on a mirror placed on the platter. Once the azimuth setting is correct, gently re-tighten the

azimuth setting screw.

ESSENTIAL III SPECIFIC INFORMATIONS

Controls, features and connections

1 ON/OFF SWITCH

2 STEPPED DRIVE PULLEY

3 OUTPUT CABLE CONNECT IT E

_____________________________________________________________________________________________________________

Switching on and off

Pressing the ON/OFF switch alternately starts or stops the motor.

Changing replay speed

To play 45 r.p.m., put the drive belt over the larger diameter part of the motor pulley. To revert to 33

r.p.m. repeat the proceedings using the smaller step on the pulley.

Connection to the amplifier

The record player has a captive tonearm signal lead for connection to the amplifier. Use the Phono input on

your amplifier. Make sure that the phono input offers correct matching and amplification for the type of

cartridge used. Line inputs (such as CD, Tuner, Tape or Video) are not suitable.

Take care to connect the left and right channels correctly. The right channel is usually marked red, the

left channel black or white. Check the manual supplied with your amplifier for relevant information.

The earthing wire of the tonearm lead should be connected to the earth terminal on your amplifier (if

provided).

If your amplifier does not have an input suitable for phono cartridges you will require a separate

phono amplifier stage for MM or MC cartridges which is then connected between the record player and

a free line level input of the amplifier.

ESSENTIAL III Bluetooth SPECIFIC INFORMATIONS

Controls, features and connections

1 ON/OFF SWITCH

2 STEPPED DRIVE PULLEY

3 PHONO/LINE OUTPUT, EARTH CONNECTION

4 BLUETOOTH SWITCH

_____________________________________________________________________________________________________________

Switching on and off

Pressing the ON/OFF switch alternately starts or stops the motor.

Changing replay speed

To play 45 r.p.m., put the drive belt over the larger diameter part of the motor pulley. To revert to 33

r.p.m. repeat the proceedings using the smaller step on the pulley.

Connection to the amplifier

The record player has two possible outputs – Line OUT with integrated preamplifier and Phono OUT for

connection to the preamplifier. If you choose Phono OUT, than use the Phono input (sometimes

labelled gram, disc or RIAA) on your amplifier. Make sure that the phono input offers correct matching

and amplification for the type of cartridge used. If you choose Line OUT, than use the Line inputs (like

CD, Tuner, Tape or Video).

Take care about connecting the left and right channel correctly. The right channel is usually marked

red, the left channel black or white. Check the manual of your amplifier for relevant information. An

earthing wire may be connected to the screw terminal between the sockets if you encounter humming

problems.

Bluetooth pairing

The record player has Bluetooth output and transmit signal automatically when is connected to mains.

It is paired automatically with any device with Bluetooth receiver (such as Pro-Ject MaiA, MaiA DS,

Bluetooth Box s and Bluetooth Box E).

For pairing with other devices and portable speakers use the manual of the given product.

For restart of the Bluetooth transmitter, please turn OFF and ON the Bluetooth module by using the

switch. Restart is needed only when there is a change of the Bluetooth receiver.

ESSENTIAL III Digital SPECIFIC INFORMATIONS

Controls, features and connections

1 ON/OFF SWITCH

2 STEPPED DRIVE PULLEY

3 PHONO/LINE OUTPUT, EARTH CONNECTION

4 PHONO/LINE OUTPUT SWITCH

5 DIGITAL OUTPUT SWITCH (24bit/48kHz or 24bit/96kHz)

___________________________________________________________________________________________________________

Switching on and off

Pressing the ON/OFF switch alternately starts or stops the motor.

Changing replay speed

To play 45 r.p.m., put the drive belt over the larger diameter part of the motor pulley. To revert to 33

r.p.m. repeat the proceedings using the smaller step on the pulley.

Connection to the amplifier

The record player has two possibilities of connection to the amplifier.

The analog output:

The record player has gold plated female RCA phono sockets and possibility to choose between Phono and

LINE output. With LINE OUT on, you can use a line input (such as AUX, CD, Tuner, Tape or Video) on your

amplifier. With PHONO OUT on, you can use your own phono pre-amplifier (sometimes labelled gram, disc

or RIAA).

Take care to connect the left and right channels correctly. The right channel is usually marked red, the

left channel black or white. The earthing wire of the tonearm lead should be connected to the earth

terminal on your amplifier (if provided).

The digital output:

The record player has digital S/PDIF output through optical connector with switch between

24bit/48kHz and 24bit/96kHz. Use the optical input on your amplifier, AV receiver or D/A converter.

Optical cable is not supplied with the record player. Your dealer can help you with selection of the

optical cable.

ESSENTIAL III Recordmaster SPECIFIC INFORMATIONS

Controls, features and connections

1 SPEED CONTROL

2 DRIVE PULLEY

3 PHONO/LINE OUTPUT, EARTH CONNECTION

4 PHONO/LINE OUTPUT SWITCH

___________________________________________________________________________________________________________

Switching on and off, changing replay speed

To play records at 33 r.p.m. press the speed control switch to starts the motor. Pressing the ON/OFF

switch two times selects 45 r.p.m.. The selected speed is shown respectively by the flashing LED. When

the platter has attained full speed, the LEDs stop flashing.

A long (more than three seconds) press on the ON/OFF switch stops the motor.

Connection to the amplifier

The record player has gold plated female RCA phono sockets (14) and possibility to choose between Phono

and LINE output. With LINE OUT on, you can use a line input (such as AUX, CD, Tuner, Tape or Video) on

your amplifier. With PHONO OUT on, you can use your own phono pre-amplifier (sometimes labelled gram,

disc or RIAA).

Take care to connect the left and right channels correctly. The right channel is usually marked red, the

left channel black or white. The earthing wire of the tonearm lead should be connected to the earth

terminal on your amplifier (if provided).

Connecting to a Computer

Connect the USB-output of the unit to a free USB-socket on your computer and turn it on/make sure it

is powered on.

The “new hardware found assistant“ will automatically detect the unit and announces it as a Microphone

USB audio codec. There is no need to install a driver manually.

After installation, one setting has to be done. For example - Windows 7

operating system:

      Control Panel Sound Recording Microphone USB Audio CODEC Properties

Advanced: set to 2 channel, 16 bit, 48000 Hz (DVD Quality)

Please note: Connection should be made to an USB-socket of your computer directly. Connecting

to USB-hubs or switches can cause problems.

Recording Programme

In case you do not have a recording programme installed on your computer, you may download one free

from the Internet. Recording programmes may be found by searching Google.

In the menu of the recording programme, source or input may have to be set to Microphone USB audio

codec.

Please be aware that downloads from the Internet are made entirely at your own risk. Under no

circumstances can we carry responsibility or provide support for third-party software products

sourced from the internet or for any damage or problems arising from the use thereof. All

downloads should be checked with an up-to-date anti-virus programme. License fees may be

applicable.

Produktspecifikationer

Varumärke:	Pro-Ject
Kategori:	Skivspelare
Modell:	Essential III Bluetooth

Behöver du hjälp?

Om du behöver hjälp med Pro-Ject Essential III Bluetooth ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Skivspelare Pro-Ject Manualer

Pro-Ject X8 B Bruksanvisning

29 Mars 2025

Pro-Ject Debut PRO S Balanced Bruksanvisning

20 Februari 2025

Pro-Ject Metallica Limited Edition Bruksanvisning

20 Februari 2025

Pro-Ject Signature 12.2 Bruksanvisning

6 Januari 2025

Pro-Ject VT-E BT Bruksanvisning

31 December 2025

Pro-Ject The Classic Reference Bruksanvisning

28 December 2024

Pro-Ject X2B Bruksanvisning

11 December 2024

Pro-Ject T1 EVO Phono Bruksanvisning

7 December 2024

Pro-Ject T1 EVO Bruksanvisning

7 December 2024

Pro-Ject T1 EVO BT Bruksanvisning

7 December 2024

Skivspelare Manualer

Nyaste Skivspelare Manualer

Audio-Technica VM520EB/H Bruksanvisning

31 Maj 2025

Crosley Dean CR6237A Bruksanvisning

12 Mars 2025

Crosley Cruiser Deluxe CR8005E Bruksanvisning

12 Mars 2025

Crosley T150C Bruksanvisning

12 Mars 2025

Crosley Cruiser Plus CR8005DP Bruksanvisning

12 Mars 2025

Crosley C92A Bruksanvisning

12 Mars 2025

Sumiko Black Pearl Bruksanvisning

21 Februari 2025

Sumiko Pearl Bruksanvisning

21 Februari 2025

Soundmaster PL560 Bruksanvisning

20 Februari 2025

Monster MT-TT249NB Bruksanvisning

19 Februari 2025
