Item No. 539676 - Holder with Tilt Swivel and Key

Lock

Compatible with:

Samsung Galaxy Tab Active

Important:

Self-installation instructions and advice are provided for your

convenience. It is your responsibility to determine if you have the

knowledge, skills, and physical ability required to properly perform an

installation. ProClip USA, Inc. shall have no liability for damage or

injury resulting from the installation or use of any ProClip or third

party products. It is your responsibility to ensure that all products are

installed in adherence with local laws and regulations and in such a

manner as to allow a vehicle to be operated safely and without

distraction. ProClip USA, Inc. product warranties do not cover the

installation, removal or re-installation of any product.

Attention:

Carefully read all instructions and review the images before installing this product.

1. Unscrew the screw in the center of the holder so you can remove the tilt

swivel base plate on the back. Place the tilt swivel base plate over the matching

holes in the face plate of your mounting bracket (ProClip demo mount shown in

picture) Attach the base plate by using the self-tapping screws enclosed. Place

the Holder onto the tilt swivel base plate and attach it with the center screw.

This screw also controls the pivot, tighter for a rm hold and loose for more

(easier) angling/rotation of the Holder.

3. To remove the tablet from the holder: Use the enclosed key to open the lock.

Remove the lock by sliding it away from the holder. Slide the tablet carefully out

of the holder.

2. o place the device in the holder: Hold the device in an angled position, screen

facing downwards. Place the lower part of the device into the holder where the

opening between the sidewalls is widest. Flip the upper part of the device forward so

the device goes at into the holder. Slide the device straight downward into the holder.

Press the block with the lock downward onto the upper part of the holder and press

the button to lock it.

4. The holder and tablet is in place. Switch between portrait and landscape view by

rotating the holder to desired position.

Produktspecifikationer

Varumärke:	Proclip
Kategori:	Inte kategoriserad
Modell:	539676
Ursprungsland:	Sverige
Material:	ABS
Kompatibilitet:	Galaxy Tab Active
Rotationsvinkel:	15 °
Maximal skärmstorlek:	8 "
Produktens färg:	Svart
Antal per förpackning:	1 styck
Brand kompatibilitet:	Samsung
Lås typ:	nyckel
Antal nycklar som medföljer:	2 styck
