Sida 1/10

[en] Instruction manual

Gas hob

! Pan supports

" Control knobs

# Auxiliary burner (up to 1 kW)

$ Semi-rapid burner (up to 1.75 kW)

% Rapid burner (up to 3 kW)

& Double-flame wok burner (up to 3.3 kW)

' Electric hob 1000 W

2&$









2&$(









2$+'









Ú Table of contents

[en]Instruction manual

Safety precautions .....................................................................3

Your new appliance ....................................................................5

Accessories .........................................................................................5

Gas burners ................................................................................5

Switching on manually .......................................................................5

Switching on automatically................................................................5

Safety system ......................................................................................6

Switching off a burner........................................................................6

Power levels.........................................................................................6

Warnings...............................................................................................6

Cooking guidelines.............................................................................6

Electric hob.................................................................................6

Power control switch ..........................................................................6

Suggestions .........................................................................................7

Cooking pans..............................................................................7

Suitable pans.......................................................................................7

Precautions for use ............................................................................7

Cleaning and maintenance........................................................8

Cleaning................................................................................................8

Maintenance ........................................................................................8

Trouble shooting ........................................................................ 8

Technical Assistance Service ...................................................9

Warranty conditions............................................................................9

Used appliances and packaging...............................................9

Environmentally-friendly disposal.....................................................9

: Safety precautions

Read these instructions carefully. You will

only be able to use your appliance safely

and effectively when you have read them.

These operating and installation instructions

should be retained, and passed onto the

buyer if the appliance is sold.

The manufacturer is exempt from all

responsibility if the requirements of this

manual are not complied with.

The images shown in these instructions are

for guidance only.

Do not remove the appliance from its

protective packaging until it is installed in

the unit. Do not switch on the appliance if it

is damaged in any way. Contact our

Technical Assistance Service.

This appliance is class 3 type, according to

the EN 30-1-1 regulation for gas

appliances: built-in appliance.

Before installing your new hob, ensure that

it is being installed according to the

assembly instructions.

This appliance cannot be installed on

yachts or in caravans.

This appliance must only be used in well

ventilated places.

This appliance is not intended for operation

with an external clock timer or a remote

control.

All operations relating to installation,

connection, regulation and conversion to

other gas types must be performed by an

authorised technician, respecting all

applicable regulations, standards and the

specifications of the local gas and

electricity suppliers. Special attention

shall be paid to ventilation regulations.

This appliance leaves the factory set to the

gas type that is indicated on the

specifications plate. If this needs to be

changed, please consult the assembly

instructions. It is recommended you contact

the Technical Assistance Service to change

to another gas type.

This appliance has been designed for home

use only, not for commercial or professional

use. This appliance is only intended for

cooking purposes, not as a heating system.

The warranty will only be valid if the

appliance is used for the purpose for which

it was designed.

Never leave the appliance unattended

during operation.

Do not use lids or protective barriers for

children which are not recommended by the

hob manufacturer. They may cause

accidents such as those due to the

overheating, ignition or detachment of

fragments of materials.

This appliance may be used by children

8 years old and older and by persons with

reduced physical, sensory or mental

capacity or a lack of experience or

knowledge if they are supervised or they

have been instructed about the safe use of

the appliance and have understood the

associated dangers.

Never let children play with the appliance.

Cleaning and user maintenance must not

be carried out by unsupervised children.

Produktspecifikationer

Varumärke:	Profilo
Kategori:	Ugn
Modell:	OCA652
Inbyggd display:	Nej
Timer:	Nej
Vikt:	11000 g
Bredd:	590 mm
Djup:	520 mm
Höjd:	45 mm
Sladdlängd:	1 m
Förpackningens bredd:	580 mm
Elektronisk tändning:	Ja
Antal gasbrännare:	4
Certifiering:	CE
Ramfärg:	Svart
Produktens färg:	Svart
Kontrolltyp:	Rotations-
Låddjup:	650 mm
Vikt inkl. förpackning:	12000 g
AC-inspänning:	220-240 V
Apparatens placering:	Inbyggd
Växelström Frekvens:	50 - 60 hz
Ström:	3 A
Installationsfack, bredd:	560 mm
Installationsfack, djup:	480 mm
Installationsfack, höjd:	45 mm
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	4
Kokzon 3, form:	Rund
Placering av platta/tillagningsyta 4:	Höger fram
Typ av platta/tillagningsyta 4:	Sjudning
Typ av platta/tillagningsyta 3:	Vanlig
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Höger bak
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	gas
Typ av platta/tillagningsyta 1:	Vanlig
Placering av platta/tillagningsyta 2:	Främre till vänster
Strömförsörjning till platta/tillagningsyta 4:	gas
Strömförsörjning till platta/tillagningsyta 2:	gas
Typ av platta/tillagningsyta 2:	Stor
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	gas
Placering av platta/tillagningsyta 1:	Vänster bak
Sjuda brännare / kokzon:	1000 W
Regelbunden brännare / kokzon:	1700 W
Stora brännare / kokzon:	1700 W
Manöverplats:	Övre höger
Effekt på platta/tillagningsyta 1:	1700 W
Effekt på platta/tillagningsyta 2:	3000 W
Effekt på platta/tillagningsyta 3:	1700 W
Extra stor hög hastighet brännare / kokzon:	3000 W
Effekt på platta/tillagningsyta 4:	1000 W
Typ av ytskikt:	Glas
Anslutningseffekt (elektrisk):	1 W
Anslutningseffekt (gas):	7400 W
Material i hällstativ:	Rostfritt stål
Gastyp:	Gasol (LPG)
