Assembly & Installation Instructions
CAUTION: Read instructions carefully and turn electricity off at
main circuit breaker panel before beginning installation.
P2666
CAUTION: P2666 45° CANOPY ONLY TO BE USED WITH THE FOLLOWING PROGRESS LIGHTING FAN
MODEL NUMBERS: P2501, P2503, P2521, P2526, P2530, P2531, P2533, P2539, P2584.
CAUTION: Risk of re. Min. 90°C supply conductors. Consult a qualified electrician to ensure correct branch
circuit conductor.
WARNING: If any special control devices are used with this xture, follow the instructions carefully to assure full
compliance with N.E.C. requirements. If there are any questions, contact a qualied electrical contractor.
45° CANOPY KIT
Design allows remote control receiver to be
installed within canopy up to a 45° angle.
Unpacking the Kit
1. Identify all the included components:
A. Mounting bracket with 4 canopy screws
B. Canopy
C. Canopy ring
D. Hanger ball
E. Metal clamp plate
F. Plastic gasket
G. Screw
EFG
Electrical box
A
Screw
D
C
Downrod
(not included)
B
Instructions
1. Turn off the power supply before installation.
2. The electrical box and support structure must be
securely mounted and capable of reliably supporting
35 lbs (15.9 kg) or less.
3. Remove the canopy ring (C) from the canopy (B) by
turning the ring to the right until it unlocks. (Figure A)
4. Remove the mounting bracket (A) from the canopy
(B) by loosening the four screws on the top of the
canopy (B). Remove the two non-slotted screws and
loosen the slotted screws. This will enable you to
remove the mounting bracket (A). (Figure B)
Figure B
Figure A
Customer Service: 1-800-447-1723PAGE 1 of 2
SPEC.NO. 93102260 03/15/2019
TURN CANOPY TO REMOVE
LOOSEN BUT DO NOT REMOVE
REMOVE
