Take the cardboard template that comes with the speakers and
place it where you want the speaker to be mounted.
Draw around the template and cutout the speaker mounting hole.
Run quality speaker wire (12-16 gauge ) to that location.
Carefully pry off the grill from the speaker either using a small
screwdriver at the edge of the grill or with a small awl catching the
grill by one of its holes.
Connect the speaker wire to the speaker terminals and insert the
speaker into the hole.
There are screws around the perimeter of the face of the speaker
(6 on the inwalls). These screws connect to ‘wings’ in th
e rear of the
speaker which will swing out and clamp the speaker to the wall as they
are tightened.Secure the speaker to the wall by tightening these screws
until the speaker is securely mounted.
Reattach grill.
That’ s It ! Enjoy !
In-wall Speakers
Cutout Dimensions
BQ 260: 183 x 183mm
BQ 108: 247 x 247mm
BQ 360: 183 x 119mm
BQ 450: 356 x 148mm
BQ Series
Produktspecifikationer
| Varumärke: | Pure Acoustics |
| Kategori: | högtalare |
| Modell: | BQ 450 |
