Sida 1/5
Thank you for purchasing the PYLE Audio PDA35BT Class T Digital Audio Power Amplifier. This amplifier features the
Tripath TP2050 chipset that provides 50W contin uous power per channel (100W total) into an 8 ohm load. Class T
amplifiersusesTripath’sproprietaryDigitalPowerProcessingTechnologyoffertheaudiofidelityofa
ClassABamplifier
whileprovidingthepowerefficiencyofaClassD.
FrontPanel:
1.PowerLED
RedpowerLEDindicatestheunitisreceivingpowerandisfully operational.
2.BluetoothLED
BlueBluetoothLEDindicatestheunitisreceivingtheBTsignal.
3.BT/LINEInputSwitch
ModebuttonswitchesbetweentheBluetoothandLineaudioinputs.PushinisforBluetoothfunction,and
pushoutis
forlineaudioinput.
4.1/4''HeadphoneJack
The PDA35BT is a high fidelity headphone amplifier that will drive any headphone easily and delivers colossal sound
stageandeffortlessdynamicrang.The1/4''stereojackallowsconnectionoflargerhomeandstudio‐styleheadphon es.
Anadapteris
alsoprovidedsothatsmaller3.5mmpersonnelstyleheadphonescanbeused.
Note:Whenheadphonesarepluggedintotheheadphonejack,thespeakeroutputconnectionsaredisconnected.
5.Power/VolumeControl
Thiscontrolturnsontheunitandadjuststhevolumeleveloftheamplifier.Whentheunitisturned
on,thepowerLED
will became fully illuminated. To turn the unit off, turn the control fully counterclockwise until it “clicks” to the off
position.ItisnormalforthepowerLEDtoslowlydimandthengocompletelyoutwhentheunitisfirstturnedoff.
6.3.5mm
Aux/AudioInput
The unit features a convenient front mounted 3. 5mm stereo input for quick connection of iPods, MP3 players, and
otherportableaudiodevices.
RearPanel:
7.BluetoothAntenna
UsingtheantennaisbestreceivingforBluetoothsignal.
8.SpeakerOutputs
Thespeaker output connectionsutilize high current banana plug receptacles thatare spaced on3/ 4'' centersand are
compatiblewithstandard doublebanana plugconnectors (soldseparately).Theconnectionsarecolorcodedfor
easy
polarityidentification.Highqualityscrew‐onbananaplugsthatwillaccept10AWG‐18AWGwireareincluded
9.RCA‐TypeAudio/LineInput
RCA‐typelinelevelinputforpermanentconnectionoflargerdevicessuchasCDplayers,PCs,andDVDplayers.AnRCA
to 3. 5mm adapter is also provided
for added connection flex ibility. Note: When a device is plugged into the front
mounted3.5mminput,theRCAinputjacksaredisconnected.
