Sida 1/5

WARNING: Failure to read and follow these warnings and instructions may result in serious injury, including damaged

property, so please pay close attention and exhibit the utmost care.

• The Digital Backup Camera is designed as an aid to the driver in detecting potentially hazardous driving conditions,

obstructions, ou, the driver, must and large stationary objects. Y also remember to drive safely and properly. Use of the

Digital Backup Camera is not a substitute for safe, proper and legal driving practices.

• Never back up while looking only at your connected monito screen. You should always check behind and around r display

the vehicle when backing up just as you would if the vehicle did not have the Digital Backup Camera. Always make sure

your driving area is clear. Always back up slowly and with caution.

• Never depend on the Backup Camera entirely when backing up. The image on the screen monitor display may be slightly

different from actual and real conditions. Objects viewed in the rear view monitor differ from actual distance -time s

because a wide sed. -angle lens is u So use the camera as an aid and always follow intended driving practices to properly

judge distances from objects.

• The Backup Camera's assisted low lux lighting performance feature is also an aid to a driver. Always use your own eyes

to confirm the vehicle’s surroundings, as the displayed image may be not well lit or not entirely visible. Always proceed

with caution and perform double before proceeding. -checks

• The area displayed by the Backup Camera is limited. It does not display objects that are close to or below the just

bumper, underneath the vehicle, or objects out of the camera’s view. The camera's view can change according to your

vehicle's orientation on the road or changing road conditions.

• Be sure to check the camera is properly functioning, is properly positioned securely ed and mount , every time you

operate your vehicle.

• Make sure operates correctly, as intended, before and after installationyour trunk hatch or .

• Avoid excess water exposure around the camera Proceed with caution when cleaning your vehicle around the camera.

especially with spraying or a power washer.

• Please make sure to keep the camera clean and unobstructed from any debris

• Follow all traffic laws and motor vehicle regulations.

• Consult local laws and regulations for any restrictions on installation or use.

• Using a Backup Camera System is not adequate enough to completely eliminate a vehicle’s blind spot. Always remember

to drive with caution, following all traffic laws.

Please read all of the installation instructions carefully before installing the product. Improper installation will void

manufacturer’s warranty. The installation instructions do not apply to all types of vehicles, and are written as

guidelines to assist in installing the system. Please consult an experienced technician if you are not comfortable

installing the product. Prior to using and installing the Backup Camera System, please read the safety information

provided in this user manual. Be sure to use the product as outlined in this user manual. Altercation or modifications

carried out without appropriate authorization may invalidate the user's right to operate the equipment.

System Installation and Wiring

Notes:

Camera System installation on different types of vehicles require slightly different wiring install These installation may s.

instructions do not apply to all types of vehicles. They are meant only as a general guide due to the large number of

vehicle makes and models. Consult your local motor vehicle laws, and installation professional, on the use of this product

to be sure it is permitted, and for optimum performance operation.

Through installation of this backup camera system, you should be sure as to not degrade, damage or compromise the

safety of any system or device on your vehicle.

Improper installation and wiring of the vehicle amera system may damage the vehicle's electrical system, b u cack-p

including vital vehicle computer and operating systems. That could lead to an accident or fire, causing property damage

and /or serious personal injury. It is highly recommended to seek professional installation advice from a qualified auto

electrician or, in the alternative, to have the installation performed by a qualified auto electrician.

Please ensure that monitor is secured and mounted where it would NOT obstruct any OEM vehicle safety features.

In an event of an accident, manufacturer is not responsible for bodily injury caused by the monitor being a projectile.

Select location for mounting the monitor in desired location. Ensure monitor location will not obstruct your vision while

driving.

The manufacturer assumes no liability for damage caused to your vehicle due to improper installation or use.

Quick Installation:

The 2.4 G wireless modules come in two parts, as the tter” the “Receiver”labeled “Transmi and . The transmitter and

receiver come equipped with built hen installing the should be connected to the -in power wiring cables. Wtransmitter it ,

camera (the camera is preferably in the rear of the vehiclemounted , just above the lice The eceiver nse plate). r connects

to the included display monitor. Th receives the signal from the camera connected to the is transmitter.

Connect the transmitter's red power wire of the DC 12V input cable, to the positive 12V reverse tail light in the rear of ,

your car. Then connect the black wire of the DC 12V input and ground properly. The transmitter then plugs in, cable, to

the camera, and will supply power to the camera directly.

Next, connect the yellow RCA Video connector to the RCA Video output of the transmitter. cable Try to run this yellow

video cable through the least obtrusive and non in your vehicle-interfering route . The transmitter will automatically

broadcast the video signal to the receiver wirelessly once activated (once your vehicle is placed in reverse).

Then, grab the other wireless module (receiver) and use the red wire, of its DC 12V input cable, to connect this to your

vehicle's fuse panel (preferably to the positive 12V ignition switch voltage) which will only be powered when your vehicle -

is on, or activated by key. Then connect the black wire , , of the DC 12V input and ground properly. The receiver should be

connected to the monitor, and will supply power to the monitor directly.

Caution: This unit is designed to operate on a 12V/24V DC NEGATIVE GROUND electrical system. Connecting to other types of electrical

systems will cause damage to your vehicle. Please contact the manufacturer if you are unaware of the system type in your vehicle.
