Pyle PLMRA620 Bruksanvisning

Pyle mottagare PLMRA620

Läs gratis den bruksanvisning för Pyle PLMRA620 (8 sidor) i kategorin mottagare. Guiden har ansetts hjälpsam av 21 personer och har ett genomsnittsbetyg på 4.5 stjärnor baserat på 11 recensioner. Har du en fråga om Pyle PLMRA620 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/8

All Pyle products are carefully constructed and thoroughly tested before

shipment. Products purchased in the USA are warranted to be free of defects

in material and workmanship for two (2) years from the date of purchase. This

warranty is limited to the original retail purchase.

Should the product fail due to factory defects in material or workmanship,

your unit will be repaired or replaced at the sole discretion of Pyle.

To obtain warranty service you must first call our Consumer Return Hotline

number at (718) 236-6948 to obtain a Return Authorization number. This

R.A.# must appear on the outside of your package and on all paperwork

relating to your return.

When returning a product to us for warranty service it must be carefully packed

and shipped prepaid to:

You must also include the following items:

• A copy of your sales receipt or other proof of purchase

• A brief letter indicating the problem you are experiencing

• include in your letter your return address, daytime phone number,

and R.A. number

• also include a check or money order for $18.00 for return shipping,

handling, and insurance, or provide your Visa/MC number with

expiration date.

R.A.#

Pyle Service Center

1600 63rd Street

Brooklyn, NY 11204

Our obligation under this warranty is limited to the repair or

replacement of the defective unit when it is returned to us prepaid.

This warranty will be considered void if the unit was tampered with,

improperly serviced, or subject to misuse, neglect, or accidental

damage.

l i m i t e d w a r r a n t y p o l i c y

w w w . p y l e a u d i o . c o m

a m p l i f i e r s

c o n g r a t u l a t i o n s . . .

t a b l e o f c o n t e n t s

electrical connections

1/2/3/4 channel input connections

features and specifications

P L M R A 6 2 0

general features

P L M R A 6 2 0

3-4

mono input connections

P L M R A 6 2 0

speaker connections

mounting and installation

protection circuitry and troubleshooting

precautions

P L M R A 6 2 0

on your purchase of a Pyle

Marine

Series amplier. This amplier

extends the Pyle tradition into a totally new series of amps, designed

from the ground up to deliver the power, performance and exibility

the modern car audio enthusiast demands.

When you check the list of features oered by the PLMRA620

you’ll

know you made the right choice with a Pyle

Marine

amplier.

g e n e r a l f e a t u r e s

· 100 Watts x 4 Output.

250 Watts x 2 Output.

· 250 W x 4.

500 W x 2 Bridged Output ( 400 W x 2 + 900 W x 1)

· Variable Hi/Lo Electronic Crossover Network ( CH1/CH2/ and CH3/CH4)

· Variable Bass Boost (0 - 18 dB @ 60Hz) ( CH5/CH6)+

· Variable Input Level (Gain) Control

· Low and High Pass Filter Controls( CH3/CH4)

· Remote Turn On/O

· Gold Plated RCA Inputs

· Power ON LED Indicator

· LED Protection Indicator

· S/N Ratio: > 95 dB

· THD: <0.04%

· Thermal Protection

· Overload Protection

· Short Circuit Protection

· Anti-Thump Turn-On

· Blue LED Level Display

PLMRA620

High Performance 2000 Watt 6 Channel

Bridgeable MOSFET Amplier

f e a t u r e s a n d s p e c i f i c a t i o n s

PLMRA620

6 c h a m p P L M R A 6 2 0

Produktspecifikationer

Varumärke:	Pyle
Kategori:	mottagare
Modell:	PLMRA620
Inbyggd display:	Nej
Bredd:	276 mm
Djup:	498 mm
Höjd:	69.5 mm
LED-indikatorer:	Power, Status
Volymkontroll:	Digital
Material:	Gjuten aluminium
Ljudutgångskanaler:	5.1 kanaler
Anslutning till PC:	Nej
Total harmonisk distorsion (THD):	0.04 %
Fjärrkontroll ingår:	Ja
Ingångskänslighet:	250 mV
Diskantjustering:	Nej
Toppeffekt per kanal:	500 W
Förstärkarklass:	D
RMS uteffekt per kanal (4 Ohm):	250 W
Linjeingångar (RCA):	3
Multi-Zone kapacitet:	Ja
RMS uteffekt per kanal (2 Ohm):	400 W
Basförstärkning:	0 - 18 dB
Inbyggd crossover:	Ja
Produktens färg:	Blue, Silver
bruksanvisning:	Ja
Uteffekt (RMS):	2000 W
Effekt skyddsfunktioner:	Overheating, Overload, Short circuit
Equalizer:	Nej
Material, hölje:	Gjuten aluminium
Frekvensområde:	15 - 30000 hz
Anslutningsteknologi:	Kabel
Likströmsingång:	Ja
Strömingång:	Nej
XLR-ingång:	Nej
Högtalare anslutning typ:	Klämplintar
På / av-knapp:	Ja
Högsta strömstyrka:	60 A
Ändamål:	Bil
Skärmgränssnitt (OSD):	Nej
Ljudingång (vänster och höger):	3
Basnivåkontroll:	Ja
Signal/brusförhållande (SNR):	95 dB
Kylning typ:	Aktiv
Likströmsdriftspänning:	12 V
Lågnivå-port:	Nej
Bridge-funktion:	Ja
Bridge-mode uteffekt per kanal (4 Ohm):	900 W
Synkroniserad ingångsimpedans:	100 Ω
Audio ingångskanaler:	5.1 kanaler
Maximal input nivå:	0.25 V
Förstärkningsjustering:	Digital
Högtalare väljare:	A+B
