Sida 1/4
LOW-PROFILE MARINE SPEAKER SYSTEM
Model: PLMRS4W - PLMRS4B
4" -inch Speaker Pairs
Model: PLMRS43WL - PLMRS43BL
4" -inch Speaker Pairs with Built-in LED Lights
Model: PLMRS5W - PLMRS5B
5.25” -inch Speaker Pairs
Model: PLMRS53WL - PLMRS53BL
5.25” -inch Speaker Pairs with Built-in LED Lights
Model: PLMRS6W - PLMRS6B
6.5” -inch Speaker Pairs
Model: PLMRS63WL - PLMRS63BL
6.5” -inch Speaker Pairs with Built-in LED Lights
www.PyleUSA.com
Speakers & Options:
Model Number LED Light
Bulb
Cut-Out
Diameter
PLMRS4W
Speaker
Size
4”
4”
4”
4”
5.25”
5.25”
5.25”
5.25”
6.5”
6.5”
6.5”
6.5”
Max Output
Power
100 Watt
100 Watt
100 Watt
100 Watt
180 Watt
180 Watt
180 Watt
180 Watt
240 Watt
240 Watt
240 Watt
240 Watt
3.7”
3.7”
3.7”
3.7”
4.7”
4.7”
4.7”
4.7”
5.3”
5.3”
5.3”
5.3”
Mounting
Depth
0.9”
0.9”
0.9”
0.9”
0.9”
0.9”
0.9”
0.9”
0.92”
0.92”
0.92”
0.92”
PLMRS4B
PLMRS43WL
PLMRS43BL
PLMRS5W
PLMRS5B
PLMRS53WL
PLMRS53BL
PLMRS6W
PLMRS6B
PLMRS63WL
PLMRS63BL
Blue Illumination
Blue Illumination
Blue Illumination
Blue Illumination
Blue Illumination
Blue Illumination
These speakers were designed and manufactured for your installation needs and have
been thoroughly tested to ensure consistent and reliable performance.
For further information, installation assistance or product troubleshooting visit us on
PyleUSA.com
Model Number Magnet Frequency
Response
PLMRS4W
Total Speaker
Diameter
5.2’’ -inches
6.4'' - inches
6.4'' - inches
7.3'' - inches
Total Speaker
Depth
1.5’’ -inches
1.6'' - inches
1.6'' - inches
1.6'' - inches
90Hz-18khz
80Hz-18khz
Speaker
Weight
0.66 lbs.(Each)
0.88 lbs.(Each)
PLMRS4B
PLMRS43WL
PLMRS43BL
PLMRS5W
PLMRS5B
PLMRS53WL
PLMRS53BL
PLMRS6W
PLMRS6B
PLMRS63WL
PLMRS63BL
3.4 Oz
5.2’’ -inches 1.5’’ -inches 90Hz-18khz 0.66 lbs.(Each)3.4 Oz
5.4 Oz
5.4 Oz 80Hz-18khz 0.88 lbs.(Each)
5.4 Oz 60Hz-18khz 0.95 lbs.(Each)
7.3'' - inches 1.6'' - inches 5.4 Oz 60Hz-18khz 0.95 lbs.(Each)
7.3'' - inches 1.6'' - inches 5.4 Oz 60Hz-18khz 0.95 lbs.(Each)
5.2’’ -inches 1.5’’ -inches 90Hz-18khz 0.66 lbs.(Each)3.4 Oz
6.4'' - inches 1.6'' - inches 5.4 Oz 80Hz-18khz 0.88 lbs.(Each)
7.3'' - inches 1.6'' - inches 5.4 Oz 60Hz-18khz 0.95 lbs.(Each)
5.2’’ -inches 1.5’’ -inches 90Hz-18khz 0.66 lbs.(Each)3.4 Oz
6.4'' - inches 1.6'' - inches 80Hz-18khz 0.88 lbs.(Each)
5.4 Oz
Features:
• Includes (2) Component Speakers
• Waterproof & Weather-Resistant Design
• Rugged Marine Grade Construction
• Low-Prole Slim Style Speaker Housing
• 2-Way Full Range Stereo Sound Reproduction
• Molded ABS Machined Basket and Grill
• Universal Standard OEM Replacement Size
• For Boat, Marine Watercraft & O-Road Vehicles
www.PyleUSA.com
Speaker Wiring
To the power DC12V.
Models: PLMRS4W - PLMRS4B
PLMRS5W - PLMRS5B
PLMRS6W - PLMRS6B
Speaker Pairs
What’s in the Box:
• (2) Marine Speakers
• (2) Speaker Connection Wires, 9.8’ ft.
Technical Specs:
• Voice Coil Type: Aluminum
• Construction Material: Engineered ABS
• Impedance: 4 Ohm
Models: PLMRS43WL - PLMRS43BL
PLMRS53WL - PLMRS53BL
PLMRS63WL - PLMRS63BL
Speaker Pairs Built-in LED Lights
Speaker Wiring
• Connect the red and black cables to
their respective positive and negative
terminals.
• Speakers ‘A’ and ‘B’ connect to an
amplier source ‘C’
• Connect the red and black cables to
their respective positive and negative
terminals.
• Speakers ‘A’ and ‘B’ connect to an
amplier source ‘C’
