QTX QA1000 Bruksanvisning
Läs gratis den bruksanvisning för QTX QA1000 (3 sidor) i kategorin mottagare. Guiden har ansetts hjälpsam av 19 personer och har ett genomsnittsbetyg på 4.3 stjärnor baserat på 10 recensioner. Har du en fråga om QTX QA1000 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/3
QA400
QA1000
QA1600
QA2400
Output Max per channel @ 4Ω
200W
500W
800W
1200W
Output RMS per channel @ 4Ω
100W
250W
400W
600W
Output Max per channel @ 8Ω
140W
340W
540W
840W
Output RMS per channel @ 8Ω
70W
170W
270W
420W
Dimensions
88 x 482 x 270mm
88 x 482 x 340mm
88 x 482 x 340mm
88 x 482 x 340mm
Weight (unpacked)
6.8kg
9.1kg
12.3kg
15.4 kg
QA Series Power Ampliers
QA400 (172.020UK)
QA1000 (172.025UK)
QA1600 (172.030UK
QA2400 (172.018UK)
19” Rackmount (2 U)
High power output
Combo XLR/6.3mm jack and RCA inputs
Speaker, 6.3mm jack and binding-post outputs
Fan cooled
Output circuit overload protection
Mains powered via IEC connector
Thank you for purchasing QTX Sound -series power amplier this QA .
This product is intended to give long term, reliable service in normal usage.
Please read these instructions before use to avoid incorrect operation and outline the functions and controls.
(1) VENTILATION GRILLE - Do not cover or restrict airow
(2) - Attenuate output levels CHANNEL A+B LEVEL
(3) - Show signal present, clipping or protect mode INDICATOR LEDS
(4) - Switches mains power on/o POWER SWITCH
(5) - Do not cover or restrict airow COOLING FAN
(6) - Check voltage and connect to mains with supplied lead IEC MAINS INLET
(7) to replace fuse, disconnect mains & open with screwdriver MAINS FUSE -
(8) Connect speakers using speaker sockets, jack or binding posts OUTPUT SECTION –
(9) Connect mixer or other audio source via combo XLR/jack or RCA L+R INPUT SECTION –
No user serviceable parts inside, refer all servicing issues to qualied service personnel.
Clean case with a lint-free dry or slightly damp cloth, keep ventilation grille and fans clear of debris.
Check mains for correct voltage as indicated near to the IEC mains inlet on the rear panel. Connect to mains
supply using the IEC cable provided.
Connect the outputs A+B speakers via speaker connectors, jack or binding posts, ensuring that the minimum to
impedance is no lower than 4 Ω per channel
When using 8Ω speakers, connect the speakers in pairs to each other and then connect one of each pair to an
amplier channel output.
Connect the mixer or audio source to either the combo or RCA input sockets
With channel A+B levels down, switch the power on.
Gradually increase channel levels and check for sound from speakers.
If there is no sound, turn down channel levels, switch o and disconnect mains and check connections if front –
panel PROTECT LEDs are lit, refer to qualied service personnel.
NO OUTPUT -
Check mains power is on and fuse is OK
Check leads and connections
Check PROTECT LEDs are not lit
Check speakers are working on another amplier
DISTORTED OUTPUT -
Reduce the input signal level. Ensure that the amplier output level is within the maximum rating of the
connected speakers and gradually increase the input signal, ensuring that the signal is clean and free from
distortion.
If protect mode is active, refer to qualied service personnel
