www.avsl.com 160.461 User Manual

QTFX-4 00

Compact Fog Machine

Item ref: 160.461 UK

User Manual

Caution: Please read this manual carefully before operating

Damage caused by misuse is not covered by the warranty

www.avsl.com 160.461 User Manual

Introduction

Thank you for choosing the QTFX-400 compact fog machine as part of your stage effects

system. This product is designed to offer professional quality performance in a neat and

manageable format.

Please read these instructions in full to gain the best results from this item and avoid damage

to the unit through misuse.

Unpacking

Your QTFX-400 should reach you in good condition and should be supplied with IEC mains

lead(s), mounting bracket and a wired handheld remote control.

If there are any signs of damage or items missing from the packaging, contact your dealer

immediately.

Warning

To prevent risk of fire or electric shock, do not expose electrical parts to rain or moisture.

If liquids are spilled on the housing or through the vents, disconnect the mains, allow the

QTFX- to dry out and have checked by qualified personnel before further use. 400 it

Avoid any impact, dropping or extreme pressure to the housing.

No user serviceable parts inside - do not open the case.

Allow the QTFX-400 to acclimatize to room temperature before operating.

Refer all servicing to qualified service personnel.

Placement

The QTFX-400 has a built-in fluid tank and should be operated in an upright position.

If free-standing, ensure that the QTFX-400 is positioned on a stable, non-slip surface.

If mounted at height, use the integral bracket and it is advisable to add a safety cable.

Safety

• Check for correct voltage and condition of IEC lead before connecting to power outlet

• Check the condition of the remote lead and ensure that it is not trapped

• This unit must be earthed

• This unit uses a heating element - do not touch the nozzle area whilst in use!

Cleaning

• Use a soft dry or slightly damp to clean the casing

• Do not use strong solvents for cleaning the unit

• It is recommended to use fog machine cleaning fluid (160.670UK) periodically

www.avsl.com 160.461 User Manual

Rear Panel

Setting up

The QTFX-400 requires fog fluid to produce the effect.

It is recommended to use one of the range of qtx fog fluids for best results.

A chart for recommended fog fluids is included further along in this document

• Unscrew the top cap of the tank and remove to fill with the selected fog fluid

• Replace the cap and close securely, ensuring the pipe is fed down to the bottom of the

bottle so a consistent flow of fluid is supplied to the machine

• Connect the supplied remote control to the female IEC on the rear panel

• Connect the IEC mains plug

Operation

• Check the fog fluid level indicator at the rear and fill if necessary

• Switch the mains power on

• Heat up time is usually between 3-4 minutes. Please ensure that the remote button is

not pressed during the heat up time.

• When the machine is ready to operate, the light on the remote control will illuminate.

You may now press the button for fog on demand

• When the remote control light is off, the QTFX-400 needs time to re-heat. Do not

attempt to produce fog until the light is lit.

• During prolonged use, periodically check that the fluid level is not empty

• Switch off when not in use. Unplug from mains if not in use for long periods

Remote control connection

(IEC female)

Mains power on/off

rocker switch

Fog fluid fill level indication

Mains inlet (IEC male)

and fuse holder
