QTX QX10BT Bruksanvisning

QTX högtalare QX10BT

Läs gratis den bruksanvisning för QTX QX10BT (4 sidor) i kategorin högtalare. Guiden har ansetts hjälpsam av 34 personer och har ett genomsnittsbetyg på 4.8 stjärnor baserat på 17.5 recensioner. Har du en fråga om QTX QX10BT eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/4

QX BT

Active Speakers with Bluetooth®

Order ref: QX8BT (178.752 ) UK

QX10BT (178.753 ) UK

User Manual

Version 1.1

Caution: Please read this manual carefully before operating

Damage caused by misuse is not covered by the warranty

QXBT User Manual

Introduction

Thank you for choosing the QXBT active speaker with Bluetooth™ technology. This versatile active speaker

can deliver playback from a paired Bluetooth device and a mic or line input source simultaneously.

Package Contents

Please check the contents to ensure that the product has been received in good condition with the

appropriate mains lead(s). If you find any accessory is missing or the product has arrived with any

problems, please contact your retailer at once.

Warning

This product contains no us -serviceable parts so make no attempt to try to fix or modify this item er

yourself as this will invalidate the warranty. We recommend you keep the original package and proof of

purchase for any possible replacement or returned demand. To prevent the risk of fire or electric shock, do

not expose this appliance to rain or moisture. To prevent electric shock do not remove the cover. No user

serviceable parts inside. Refer servicing to qualified service personnel.

Safety: Labelling Conventions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

AVIS

RISQUE DE CHOC ELECTRIQUE

NE PAS OUVRIR

This symbol indicates that dangerous voltage constituting a risk of electric shock

is present within this unit

This symbol indicates that there are important operating and maintenance

instructions in the literature accompanying this unit.

Prior to connecting mains, check the supply voltage is correct and the mains lead is OK.

Avoid ingress of water or particles into the enclosure.

If the mains or D.C. fuse blows, refer the unit to qualified service personnel

Placement

Keep the unit out of direct sunlight and away from heat sources.

Keep the unit away from moisture or dusty environments.

Mount the unit on a stable surface, 35mm pole mount or suspend using the integral flying points.

Ensure that any supporting structures have adequate load capacity for the weight of the unit.

Cleaning

Use a soft cloth with a neutral detergent to clean the cabinet, panel and controls.

To avoid damage, do not use solvents to clean this equipment.

QXBT User Manual

Rear Panel Layout

Operation

Connect any line input (CD, mp3 player, home keyboard etc.) to the QXBT speaker via the 6.3mm jack line

input (12) or alternatively, connect a microphone to the XLR mic input (11)

Turn the VOLUME control (7) down and turn the POWER switch (3) BASS and TREBLE controls fully on.

(8, 9) should remain pointing vertically (12-o-clock position).

Turn up the VOLUME control part way and test the input signal (line or microphone) for output through

the speaker. Adjust the VOLUME to the required output level and TREBLE and BASS controls to adjust the

overall tone of the output (clockwise to boost, anti-clockwise to cut).

Bluetooth™ Connection

QXBT units are fitted with a Bluetooth receiver, which is operated via a rotary control and play b(4) utton

(5) on the rear panel. When the rotary control is turned fully off, power to the Bluetooth receiver is off.

If switched off, turn the Bluetooth rotary control clockwise to switch power on to the Bluetooth receiver.

Turning the rotary control up increases Bluetooth output level halfway is a reasonable position to start –.

Press and hold the Bluetooth play button for 3 seconds and the Bluetooth indicator (6) will flash blue If .

the playback source is already paired, the connection will be made with the QXBT speaker and a chime will

sound to confirm this.

If not paired, press the play button briefly again to see the LED flash between blue and red .

At this point, the Bluetooth receiver is made visible to all Bluetooth devices in range.

Scan for Bluetooth devices on your playback source and check for a device called “ luetooth”b (lower case).

Select this device and opt to connect and your sending device should state that it is connected to

“ luetooth” for audio outputb and the LED should flash blue and a beep will confirm the pairing .

Play audio from your sending device and check for output through the QXBT speaker.

Fig.8 mains inlet

Bluetooth play button

Bass EQ control

Mains fuse holder

Bluetooth indicator

10.

Line output XLRM

Power on/off switch

Volume control

11.

Mic input XLRF

Bluetooth off/volume

Treble EQ control

12.

Line input 6.3mm jack
