1of3
AssemblyInstructionSheet#IS-ATH5006K
ForStyleATH5006K
6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
,.
..
2017QuoizelInc.
ReleasedDate:2017-11-06
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
Pleasegotoforproductcleaningtips.Gototheselection.
(6)B10CandelabraBaseBulbs60WMaximumor
(6)CandelabraBaseT8VintageBulbsarerecommendedbutnotsupplied.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.comCare+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
PackageContents
A
FixtureLoop
x1
B
6”Rod
x2
C
FixtureBody
x1
D
12”Rod
x2
AllenScrew
x6
E
Cover
x1
F
SupportArms
Assembly
x1
G
STEP1InstallCover,SupportArmsAssemblyandFixtureBody
together
-
A.Unfoldsupportarmstoproperlocations(RefertoSUPPORTARMS
DISTRIBUTION).
B.Carefullypullblackandwhitewireswithgroundwireoutofsupport
arms.Attachthetabsattheendsofsupportarmsintotheringofthe
FixtureBody(G).Alignholesontabstomountingholesonthering.
SecurebythreadingAllenScrews(D)intomountingholes.Hand
tightenuntilsnugwithscrewdrivers.
C.Tuckallslackwiresinsideofthefixturecanopyonthetopofthe
SupportArmsAssembly(F).ThreadtheCover(E)ontothehex
couplingonthetopcenteroftheSupportArmsAssembly(F).Hand
tightenuntilsnug.
E
F
G
D
MountingHole
HexCoupling
Tab
SUPPORTARMSDISTRIBUTION
SupportArm
SupportArm
Figure1
HardwareContents
AA
Crossbar
Assembly
x1
BB
Ceiling
Canopy
x1
QuickLink
x1
CC
