Sida 1/1

Type

Product Line

Type

Supported Models

DIMENSIONS

COLOR

PRODUCT DIMENSIONS

PACKING DIMENSIONS

(height x width x depth)

PACKAGE CONTENTS

MOUNTING INSTRUCTIONS

Consider the environment,

recycle where applicable.

In case of problems please contact your

reseller or sales@rackmount.it.

EMEA Ofce

Nonnenveld 27

4811 HN Breda

The Netherlands

T +31 76 200 37 40

E sales@rackmount.it

WWW.RACKMOUNT.IT

US Ofce

9201 Metric Blvd - Unit A

Austin - TX 78758

United States

T +1 512 521 03 33

E sales-us@rackmount.it

Qty Description

CISRACK

RM-CI-T4

MERAKI MX64

MERAKI MX67

MERAKI MX64W

MX67W/MX67C

Metallic Blue

80 x 520 x 270 mm

3.14 x 20.47 x 10.63 in

44 x 482 x 217 mm

1.73 x 18.98 x 8.54 in

1. Remove the 4 rubber feet from your Cisco appliance.

2. Remove the 2 bolts (situated on the front side of the appliance) from the bottom of the Cisco appliance.

3. Place your Cisco appliance backwards through the FRONT opening of the rack.

4. Turn over the rack with the Cisco appliance.

5. Use the original bolts to xate the Cisco appliance on the rack and turn it back over.

Tip: use a table edge so the appliance is pinned down to the frame and the bolt holes line up.

6. Place the power supply on the rack and tie it down with the 2 zip ties.

7. Lead the low voltage power cable through the large square hole towards the front of the rack and connect

it to the power inlet.

8. Tie the excess length of the power cable down with the 3rd zip tie.

9. Place the light pipe through the opening of the rack. See picture above.

10. Place your CisRack in your 19 inch rack.

Please ensure proper ventilation according to the network appliance manufacturer guidelines.

1 CisRack + light pipe

3 Zip ties

1 Torx T6 key (for MX64)

1 Torx T8 key

Revision 6 - 03-11-2020

Produktspecifikationer

Varumärke:	Rackmount.IT
Kategori:	ej kategoriserat
Modell:	RM-CI-T4
Bredd:	482 mm
Djup:	217 mm
Höjd:	110 mm
Förpackningens bredd:	530 mm
Modell:	Monteringsskena
Snabbinstallationsguide:	Ja
Kompatibilitet:	Cisco Meraki MX64, Meraki MX64W, Meraki MX67, Meraki MX67C, Meraki MX67W
Rackkapacitet:	1U
Produktens färg:	Blå
Monteringssats:	Ja
Låddjup:	270 mm
Antal per förpackning:	1 styck
Harmonized System (HS)-kod:	85389099
