Rackmount.IT RM-WG-T6 Bruksanvisning
Sidor 1 ej kategoriserat
Läs bruksanvisningen för Rackmount.IT RM-WG-T6 gratis online eller ladda ner PDF:en. 45 personer har tyckt att guiden var hjälpsam. Fråga om modellen? Ställ en fråga
Type
Product Line
Type
Supported Models
DIMENSIONS
COLOR
PRODUCT DIMENSIONS
PACKING DIMENSIONS
(height x width x depth)
PACKAGE CONTENTS
MOUNTING INSTRUCTIONS
Consider the environment,
recycle where applicable.
In case of problems please contact your
reseller or sales@rackmount.it.
EMEA Ofce
Wilhelminasingel 3
4818 AA Breda
The Netherlands
T +31 76 200 37 40
E sales@rackmount.it
WWW.RACKMOUNT.IT
US Ofce
9201 Metric Blvd - Unit A
Austin - TX 78758
United States
T +1 512 521 03 33
E sales-us@rackmount.it
Qty Description
WG-RACK
RM-WG-T6
RM-WG-T6i
1U
WatchGuard Red
80 x 520 x 270 mm
3.14 x 20.47 x 10.63 in
44 x 482 x 217 mm
1.73 x 18.98 x 8.54 in
WATCHGUARD
FIREBOX T40
FIREBOX T20
1. Only for Firebox T40: Place the power supply on the rack and tie it down with 2 zip ties. See
detail 1.
2. Remove the 4 rubber feet from the WatchGuard.
3. Remove two bolts from both sides of the appliance with the Torx key.
4. Place your WatchGuard unit on the rack and x the unit with the provided bolts and tighten
them lightly.
5. Only for Firebox T40: Tie the excess length of the power cable down with zip tie. See detail 1.
6. Connect the cables from your WatchGuard to the connectors.
7. Optional: use two zip ties to hold the cables together.
8. Place your WG-Rack in your 19 inch rack.
Please ensure proper ventilation according to the network appliance manufacturer
guidelines.
1 WG-Rack + RJ45 couplers
5 Zip ties
1 Torx Key
2 Bolts M3x6mm
7 Cables - 0.5 meter
Industrial version is supplied with shielded couplers and cablesRevision 4 - 19-03-2021
Produktspecifikationer
| Varumärke: | Rackmount.IT |
| Kategori: | ej kategoriserat |
| Modell: | RM-WG-T6 |
| Bredd: | 482 mm |
| Djup: | 217 mm |
| Höjd: | 44 mm |
| Förpackningens bredd: | 530 mm |
| Modell: | Monteringsskena |
| Snabbinstallationsguide: | Ja |
| Kompatibilitet: | WatchGuard Firebox T20, T40 |
| Rackkapacitet: | 1U |
| Kabellängd: | 0.5 m |
| Produktens färg: | Svart |
| Monteringssats: | Ja |
| Låddjup: | 270 mm |
| Kabel inkluderad: | LAN (RJ-45), USB |
| Antal kablar: | 7 |
| Harmonized System (HS)-kod: | 85389099 |
