Sida 1/2
www.radialeng.com
True to the Music
Radial Engineering Ltd.
®
®
True to the Music
USER GUIDE
Radial Engineering Ltd.
Classic V9
™
Classic V9
™
FEATURES
RADIAL ENGINEERING 3 YEAR
TRANSFERABLE LIMITED WARRANTY
RADIAL ENGINEERING LTD. (“Radial”) warrants this product to be free from defects in
material and workmanship and will remedy any such defects free of charge according to the
terms of this warranty. Radial will repair or replace (at its option) any defective component(s)
of this product (excluding nish and wear and tear on components under normal use) for
a period of three (3) years from the original date of purchase. In the event that a particular
product is no longer available, Radial reserves the right to replace the product with a similar
product of equal or greater value. In the unlikely event that a defect is uncovered, please call
800-939-1001 or email service@radialeng.com to obtain an RA number (Return Authorization
number) before the 3 year warranty period expires. The product must be returned prepaid
in the original shipping container (or equivalent) to Radial or to an authorized Radial repair
center and you must assume the risk of loss or damage. A copy of the original invoice showing
date of purchase and the dealer name must accompany any request for work to be performed
under this limited and transferable warranty. This warranty shall not apply if the product has
been damaged due to abuse, misuse, misapplication, accident or as a result of service or
modication by any other than an authorized Radial repair center.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN THOSE ON THE FACE
HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL EXTEND
BEYOND THE RESPECTIVE WARRANTY PERIOD DESCRIBED ABOVE OF THREE
YEARS. RADIAL SHALL NOT BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE OF
THIS PRODUCT. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY DEPENDING ON WHERE YOU
LIVE AND WHERE THE PRODUCT WAS PURCHASED.
Classic V9
™
User Guide - Part# R870 1018 00 / 09-2016 All rights reserved.
Specications and appearance are subject to change without notice.
Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam BC V3C 5M5
tel: 800-939-1001 • fax: 604-942-1010
info@radialeng.com • www.radialeng.com
Circuit Type ................ Classic Class FET buffer and classic audio grade ICs
Post-Distortion High & Low EQ ........................Variable from -10dB to +10dB
High Shelf ..............................................Switchable high frequency boost/cut
Mid Boost ........................................ Switchable 0dB, +7dB, +12dB @ 500Hz
Gain Switch ........................................Increases saturation of the drive circuit
Output Gain .......................................... Variable from unity to +48dB @ 1kHz
Footswitch .................................................................. Latching bypass switch
Power ..................................................................9VDC, adapter not included
Radial Classic Specications
OVERDRIVE-DISTORTION PEDAL
1. 9VDC POWER: Connection for 9 volt (center negative) power adapter.
Includes a cable clamp to prevent accidental power disconnection.
2. OUTPUT: High-Z ¼” connection to your amplier.
3. INPUT: High-Z ¼” connection from your instrument.
4. EQ: Powerful dual band post-distortion EQ.
5. DRIVE: Used to ne tune the drive to suit your playing style.
6. RANGE: 3-position switch used to set the gain stage:
• Low – for slight signal breakup
• Med – for crunch
• High – for full on saturation
7. LEVEL: Used to set the overall output level.
8. HIGH: Used to compensate the top end for overly bright amps or amps
that may sound too dark.
9. MID: 3-position mid-boost with at, +7dB and +12dB to accentuate signal
for solos or to fatten up the tone of a single-coil pickup.
10. FOOTSWITCH: Activates the Classic V9 with LED indicator.
11. STEEL ENCLOSURE: Heavy-duty 14-gauge steel enclosure for long life.
7
8
9 10 11
5
6
1 2 3
4
