Sida 1/2

RAM AQUA BOX™ PRO 10 SERIES

National Products, Inc. 8410 Dallas Ave S. Seattle, WA 98108 206-763-8361 www.rammount.com

RMR-INS-AQ7-1

INSERT FLEX-LENS FROM BEHIND BLACK AQUA BOX FRAME. SECURE THE

SIDE LIP OF THE LENS IN FRONT OF THE BLACK FRAME. WORK YOUR WAY

AROUND THE ENTIRE LENS TO SECURE IN PLACE. PRESS FIRMLY

AGAINST EACH CORNER TO ENSURE PROPER LENS FITMENT. CHECK

LENS FITMENT PERIODICALLY TO KEEP FITTING CONSISTENT.

CAUTION: THIS PRODUCT IS NOT INTENDED FOR

UNDERWATER USE. THE RAM AQUA BOX™ PRO

SERIES IS INTENDED TO PROTECT YOUR DEVICE

FROM SPLASH, MUD, RAIN OR OTHER HARSH

WEATHER. DO NOT SUBMERGE AQUA BOX™ UNDER

WATER. THE ELECTRONIC DEVICE IS NOT COVERED

FOR DAMAGE WHEN USING THIS PRODUCT.

FLEX LENS PLACEMENT

FOAM PAD PLACEMENT

OPTIONAL FOAM STRIPS CAN BE CUT AND CONFIGURED TO

ACCOMMODATE THIN DEVICES. FOAM STRIP CONFIGURATIONS

MAY VARY DEPENDING ON DEVICE. THE FOLLOWING EXAMPLE

DEMONSTRATES THE STANDARD USE OF EITHER FOAM STRIP.

YOUR DEVICE IS NOT REQUIRED TO MAKE FIRM CONTACT

WITH FLEX LENS IN ORDER TO BE A SECURE FIT.

SIDE LIP IN FRONT

OF BLACK FRAME

CHECK INSIDE VIEW

RAM AQUA BOX™ PRO 10 SERIES

National Products, Inc. 8410 Dallas Ave S. Seattle, WA 98108 206-763-8361 www.rammount.com

RMR-INS-AQ7-1

INSERT FLEX-LENS FROM BEHIND BLACK AQUA BOX FRAME. SECURE THE

SIDE LIP OF THE LENS IN FRONT OF THE BLACK FRAME. WORK YOUR WAY

AROUND THE ENTIRE LENS TO SECURE IN PLACE. PRESS FIRMLY

AGAINST EACH CORNER TO ENSURE PROPER LENS FITMENT. CHECK

LENS FITMENT PERIODICALLY TO KEEP FITTING CONSISTENT.

CAUTION: THIS PRODUCT IS NOT INTENDED FOR

UNDERWATER USE. THE RAM AQUA BOX™ PRO

SERIES IS INTENDED TO PROTECT YOUR DEVICE

FROM SPLASH, MUD, RAIN OR OTHER HARSH

WEATHER. DO NOT SUBMERGE AQUA BOX™ UNDER

WATER. THE ELECTRONIC DEVICE IS NOT COVERED

FOR DAMAGE WHEN USING THIS PRODUCT.

FLEX LENS PLACEMENT

FOAM PAD PLACEMENT

OPTIONAL FOAM STRIPS CAN BE CUT AND CONFIGURED TO

ACCOMMODATE THIN DEVICES. FOAM STRIP CONFIGURATIONS

MAY VARY DEPENDING ON DEVICE. THE FOLLOWING EXAMPLE

DEMONSTRATES THE STANDARD USE OF EITHER FOAM STRIP.

SIDE LIP IN FRONT

OF BLACK FRAME

CHECK INSIDE VIEW

YOUR DEVICE IS NOT REQUIRED TO MAKE FIRM CONTACT

WITH FLEX LENS IN ORDER TO BE A SECURE FIT.

RAM AQUA BOX™ PRO ACCESSORIES

National Products, Inc. 8410 Dallas Ave S. Seattle, WA 98108 206-763-8361 www.rammount.com

SOME ACCESSORIES MAY NOT BE INCLUDED IN ALL KITS

QUICK RELEASE MOUNTING CLIP

POSITION BOTTOM TWO HOLES OF AQUA BOX™

PRO ONTO THE LOCATOR PINS OF THE MOUNTING

CLIP. PRESS AQUA BOX™ BACK AGAINST CLIP TO

SNAP THE BACK RECEIVER INTO PLACE. PROVIDED

HARDWARE CONNECTS MOUNTING CLIP TO YOUR

RAM MOUNT.

SAFETY LANYARD

INSERT THIN LOOP THROUGH LEFT

SLOT UNDER THE BOTTOM OF THE

AQUA BOX™ PRO. PULL LANYARD

THROUGH THE LOOP AND TIGHTEN

TO SECURE SAFETY LANYARD.

BELT CLIP BUTTON ADAPTER

SLIDE BUTTON ADAPTER INTO BOTTOM SLOT OF AQUA BOX™

PRO. PRESS FIRMLY TO CLICK BUTTON INTO PLACE. COMPATIBLE

WITH STANDARD AFTERMARKET BELT CLIP BUTTON RECEIVERS.

RAM BELT CLIP BUTTON RECEIVER

SECURES OVER BELT CLIP BUTTON ADAPTER.

RAM AQUA BOX™ PRO ACCESSORIES

National Products, Inc. 8410 Dallas Ave S. Seattle, WA 98108 206-763-8361 www.rammount.com

SOME ACCESSORIES MAY NOT BE INCLUDED IN ALL KITS

QUICK RELEASE MOUNTING CLIP

POSITION BOTTOM TWO HOLES OF AQUA BOX™

PRO ONTO THE LOCATOR PINS OF THE MOUNTING

CLIP. PRESS AQUA BOX™ BACK AGAINST CLIP TO

SNAP THE BACK RECEIVER INTO PLACE. PROVIDED

HARDWARE CONNECTS MOUNTING CLIP TO YOUR

RAM MOUNT.

SAFETY LANYARD

BELT CLIP BUTTON ADAPTER

SLIDE BUTTON ADAPTER INTO BOTTOM SLOT OF AQUA BOX™

PRO. PRESS FIRMLY TO CLICK BUTTON INTO PLACE. COMPATIBLE

WITH STANDARD AFTERMARKET BELT CLIP BUTTON RECEIVERS.

RAM BELT CLIP BUTTON RECEIVER

SECURES OVER BELT CLIP BUTTON ADAPTER.

INSERT THIN LOOP THROUGH LEFT

SLOT UNDER THE BOTTOM OF THE

AQUA BOX™ PRO. PULL LANYARD

THROUGH THE LOOP AND TIGHTEN

TO SECURE SAFETY LANYARD.

Produktspecifikationer

Varumärke:	RAM Mounts
Kategori:	ej kategoriserat
Modell:	Aqua Box RAM-HOL-AQ7-1U
Material:	Komposit
Innermått (B x D x H):	116.3 x 62.48 x 11.94 mm
Kompatibilitet:	Apple iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G
Ytfärg:	Monokromatiskt
Maximal skärmstorlek:	3.5 "
Produktens färg:	Black, Transparent
Skyddsfunktioner:	Bump resistant, Scratch resistant, Splash proof
Brand kompatibilitet:	Apple
Inbyggt skärmskydd:	Ja
Ärendetyp:	Utbytbara fodral
Bälteshållare:	Ja
