Sida 1/5
Manual-1
QUICK START
If this is your first equalizer, please do yourself and
your speakers a favor and read at least the first five
pages. “An ounce of prevention...,” and all that.
The SEQ 30L is a stereo equalizer, so adjusting
any slider affects both channels simultaneously. Begin
by setting all sliders to their center detent (0 dB), and
the INPUT LEVEL to its center detent (0 dB). Try to
make more cuts than boosts. After equalizing, use the
EQ switch to compare equalized and non-equalized
signal. While EQ is switched to ACTIVE (out), adjust
the INPUT LEVEL to the same level as when EQ is
switched to BYPASS (in).
You may use either the XLR or ¼" connectors for
Inputs or Outputs. Connect only one INPUT type per
channel. The XLR and ¼" TRS inputs do not sum.
You may, however, use both types of OUTPUTS
simultaneously if desired.
WEAR PARTS: This product contains no wear parts.
OPERATORS MANUAL
SEQ 30L
STEREO GRAPHIC EQUALIZER
Manual-2
EQ BYPASS switch
When pressed to BYPASS, the filter sliders have no effect. Since actual unity
gain depends on varying slider settings, use the BYPASS switch to determine the
unity gain position of the INPUT LEVEL control by comparing ACTIVE and
BYPASS volumes.
Filter level slide controls
Each of these sliders control the
output level of both channels of the 30
bandpass filters. Center position is
grounded for guaranteed flat response.
Cable Wiring
In agreement with IEC and AES/ANSI standards, XLR wiring convention is pin
2 Positive (hot), pin 3 Negative (cold), and pin 1 Signal ground (for unbalanced
use). Pin 1 and the connector case or shell are tied to chassis ground.
INPUT LEVEL control and indicators
This controls the overall level. 0 dB gain is reached at the center detent with all
sliders centered at their 0 dB detents. Set the INPUT LEVEL to give equal volumes
with the EQ switched to ACTIVE or BYPASS, after setting the sliders (see EQ
BYPASS switch below). Apply sufficient signal to the input to occasionally light
the +4 dBu indicator. Flashing of the OL (overload) LED during peaks can be
avoided by turning the INPUT LEVEL or boosted Filters down.
