Operating Instructions

Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725

Ph: 800-444-3134 / 260-248-8188 • Fax: 800-444-4587 / 260-248-2605

Customer Service: 855-634-9109 • [email protected] • www.reelcraft.com

Series 7000 Spring Driven Hose Reels

Low, Medium and High Pressure Model Numbers:

7600 OLP7830 OLP7925 OLP7830 OMP7600 OHP

7640 OLP7840 OLP7600 OMP7840 OMP7640 OHP

7650 OLP7850 OLP7630 OMP7850 OMP7650 OHP

7607 OLP7640 OMP7400 OHP7650 OLP-HTH7850 OLP121

7670 OLP7650 OMP7440 OHP7850 OLP-HTH1217850 OLPSW57

7800 OLP7900 OLP7800 OMP7450 OHP7925 OLP-HTH

Read this manual carefully before installing, operating or

servicing this equipment.

IMPORTANT

Dimensions

A20 1/4”

B19 3/4”

C7 13/16”

D3 7/8”

E7”

• Ensure that reel is properly installed before connecting input and

output hoses.

• Bleed fluid/gas pressure from system before servicing reel.

• Before connecting reel to supply line, ensure that pressure does

not exceed maximum working pressure rating of reel.

• Remember, even low pressure is very dangerous and can cause

personal injury or death.

• Be aware of machinery and personnel in work area.

• If a leak occurs in the hose or reel, remove system pressure

immediately.

• A high tension spring assembly is contained within the reel.

Exercise extreme caution.

• Pull hose from reel by grasping the hose itself, not the control

valve.

• Ensure that reel, hose, and equipment being serviced are

properly grounded. Use an ohmmeter to check ground

continuity.

• If reel ceases to unwind or rewind, remove system pressure

immediately. Do not pull or jerk on hose!

• Treat and respect the hose reel as any other piece of machinery,

observing all common safety practices.

SAFETY

Personal injury and/or equipment damage may result if proper safety

precautions are not observed.

Form# 829-696A Rev: 1/2022
