INSTALLATION MANUAL

Flat Panel Ceiling Mount

ISSUED: APR. 2013

CAUTION: DO NOT EXCEED

RATED LISTED WEIGHT. SERIOUS

INJURY OR PROPERTY DAMAGE

MAY OCCUR!

23126

70"

MAX

200x200/300x300

400x200/400x400

600x400/800x400

(

)

RATE

ATE

ATED

75kg

(165lbs)

RATED

6. Adjustment

Loosen the knob to tilt the TV to

obtain the desired angle then

tighten it.

360°

3 6

0°

° 360°

+15°

-1°5

Knob

Maintenance

• Check that the bracket is secure and safe to use at regular intervals(at least every three months).

• Please contact your distributor if you have any questions.

reflecta gmbh

Merkurstrasse 8

72184 Eutingen i.G.

Germany

mail@reflecta.de

www.reflecta.de

Package M

NOTE: Read the entire instruction manual before you start installation and assembly.

Component Checklist

WARNING

IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation.

If any parts are missing or faulty, telephone your local distributor for a replacement.

axle pin &

safety bolt (x2)

adapter bracket (x2)

top pipe (x1)

bottom pipe (x1)

1"diameter tube(x2)

axle pin &

safety bolt (4)

arm assembly(x1)

plastic cover(4)

vise assembly

(big) (x2)

vise assembly

(small) (x4)

M5x14 (x4)

M-A

M6x14 (x4)

M-B

washer

M-F

(x4)

M8x20 (x4)

M-C

big spacer (x4)

M-H

M6x30 (x4)

M-D

M8x30 (x4)

M-E

small spacer (x8)

M-G

M8 nut (x1)

M8x60

(x1)

M8x16 x2( )

M8 (x4)x70 iron expansion bolt

5 A 2

mm llen key (x )

• Do not begin the installation until you have read and understood all the instructions

and warnings contained in this installation sheet. If you have any questions

regarding any of the instructions or warnings, please contact your local distributor.

• This mounting bracket was designed to be installed and utilised ONLY as

specified in this manual. Improper installation of this product may cause damage

or serious injury.

• This product should only be installed by someone with good mechanical ability

who has basic building experience and fully understands this manual.

• Make sure that the supporting surface will safely support the combined weight of

the equipment and all attached hardware and components.

• Always use an assistant or mechanical lifting equipment to safely lift and position

the equipment.

• Tighten screws firmly, but do not over tighten. Over tightening can cause damage

to the items, This greatly reduces their holding power.

• This product is intended for indoor use only. Using this product outdoors could

lead to product failure and personal injury.

Installers must verify that the supporting surface will safely support the combined weight of

the equipment and all attached hardware and components.

WARNING

2.For Solid Brick and Concrete Mounting

Drill four

pilot holes

60mm

(2.4")

60mm

(

()

)

45mm

(1.8")

ø 12mm

(ø 1/2")

Screw ceiling

mount on the

ceiling

Tighten all nuts but d o no t over

tighten .

1. Assembling the Pipes

Run the pow er c ab le throu gh pipe .

Attach th e bo tt om pipe to t he t op pipe

and fix the m at t he d esired h eight . Us ing

the corre ct c om binati on of scr ew a nd nut.

Mark the ex ac t

locatio n of

mountin g ho le s

Produktspecifikationer

Varumärke:	Reflecta
Kategori:	plattskärmsfäste
Modell:	Pallas XL
Rotationsvinkel:	360 °
Maximal skärmstorlek:	63 "
Minsta skärmstorlek:	32 "
Lutningsvinkel:	-15 - 15 °
Maxvikt:	75 kg
Produktens färg:	Svart
Monteringssätt:	Tak
Gränsssnitt för panelmontering:	100 x 100,200 x 100,200 x 200,400 x 200,400 x 400,600 x 400,800 x 400 mm
Höjdjustering:	Ja
Antal displayer som stöds:	1
Monteringsgränssnitt kompatibilitet (min):	100 x 100 mm
Monteringsgränssnitt kompatibilitet (max):	800 x 400 mm
Höjdjusteringsintervall:	1050 - 1620 mm
