To complete the installation secure each Control Shaft with a Shaft Nut
and Shaft Washer then plug each shaft into the side of the Radio Motor.
Use the optional hardware if needed to help mount the radio to the dash.
10
A
B
B
C
C
x(8)
E
x(10)
F
D
D
E
E
F
F
A
Attach each InfiniMount
Bracket to the Radio Motor
with the eight small screws.
Place a Shaft Nut and Shaft Washer onto each
Control Shaft before inserting them into the
InfiniMount Brackets. The Control Shaft depth and
height can be adjusted as needed.
x(2)
Optional hardware
x(2)x(4)x(2)
x(8)
D
Included in your
Radio Motor box
Control Shaft Quick Start Guide
What’s in the BoxInstallation
Hardware
Control Shaft
Modern Sound For Your Classic
[email protected] | help.retromanufacturing.com
Refer to the user manual included in your motor box or on our website for more comprehensive instructions.
