User’s Guide
Power on!
Linear High-End Audio Power Supply
Integra d and DC Mains Filter te HF
12 Volt 30 Watts Output DC
Passive / Active Filter Linear
Ultra Low Noise µFilter
Sensor Techno y log
Overload and Overheating Protection
Short Circuit Pro of
Undervoltage Detection
Status Display via s LED
GND Lift
2
User’s Guide DPS-2
Important Safety Instructions
ATTENTION! Do not open chassis risk of electric shock –
The unit has non-isolated live parts inside. No user serviceable parts inside.
Refer service to qualied service personnel.
Mains
• The device must be earthed – never use it without proper grounding
• Do not use defective power cords
• Operation of the device is limited to the manual
• Use same type of fuse only
Protection Cl 1.ass Mains connection must have protective earth (PE).
To reduce the risk of fire or electric shock do not expose this device to rain or
moisture. Prevent moisture and water from entering the device. Never leave a
pot with liquid on top of the device. Do not use this product near water, i. e.
swimming pool, bathtub or wet basement. Danger of condensation inside –
don't turn on before the device has reached room temperature.
Installation
Surface may become hot during operation ensure suicient ventilation. –
Avoid direct sun light and do not place it near other sources of heat, like radi-
ators or stoves. Leave some space between this device and others for venti-
lation.
Unauthorized servicing/repair voids warranty. Only use accessories
specied by the manufacturer.
Read the manual completely. It includes all information necessary
to use and operate this device.
User’s Guide DPS-2
3
Important Safety Instructions .................................. 2
General
1 Introduction ............................................................... 6
2 Package Contents ..................................................... 6
3 Proper Use ................................................................. 6
4 Brief Description and Characteristics 6 ....................
5 Connectors Controls Display– – ............................ 7
5.1 Connector Pinouts .................................................. 7
6 Installation a First Time Operationnd ..................... 8
7 Operating the Power Supply .................................... 8
8 Hotline Troubleshooting– 9.......................................
Technic Referen al ce
9 Technic Specications al
9.1 Mains (Primary) AC .............................................. 12
9.2 Li DC near (Secondary) ........................................ 12
9.3 D µFilter (Secondary) C ........................................ 12
9.4 General ................................................................ 12
10 al Technic Background
10.1 Dierences Linear and Switched Power Supply .. 13
10.2 AC HF and DC Filter ............................................ 14
10.3 DC Generation ..................................................... 14
10.4 Linear ................................................................... 15
10.5 µFilter ................................................................... 15
10.6 Leakage Current .................................................. 16
10.7 d Power Diagrams an Measurements .................. 17
11 Block Diagram DPS-2 ............................................. 20
Miscellaneous
12 Accessories ............................................................. 22
13 Warranty ................................................................... 22
14 Appendix .................................................................. 22
15 Declaration of Conformity ...................................... 23
