Sida 1/126

User's Guide

Fireface UFX II

The most powerful USB audio interface ever!

USB 2.0 Digital I/O System

12 + 16 + 2 Channels Analog / ADAT / AES Interface

24 Bit / 192 kHz Digital Audio

60 x 30 Matrix Router

2 x MIDI I/O

Full Stand-Alone Operation

Class Compliant Operation

MIDI Remote Control

TotalMix FX

™

24 Bit / 192 kHz 

SyncCheck

™

SteadyClock FS

™

User's Guide Fireface UFX II © RME

Important Safety Instructions

ATTENTION! Do not open chassis – risk of electric shock

The unit has non-isolated live parts inside. No user serviceable parts inside.

Refer service to qualified service personnel.

Mains

• The device must be earthed – never use it without proper grounding

• Do not use defective power cords

• Operation of the device is limited to the manual

• Use same type of fuse only

To reduce the risk of fire or electric shock do not expose this device to rain or

moisture. Prevent moisture and water from entering the device. Never leave a

pot with liquid on top of the device. Do not use this product near water, i. e.

swimming pool, bathtub or wet basement. Danger of condensation inside –

don't turn on before the device has reached room temperature.

Installation

Surface may become hot during operation – ensure sufficient ventilation.

Avoid direct sun light and do not place it near other sources of heat, like radi-

ators or stoves. When mounting in a rack, leave some space between this

device and others for ventilation.

To comply with the European CE standard, the Fireface UFX II must be used in

a CE approved Class B computer. All connecting cables must be shielded. The

computer and all cables connected to the Fireface UFX II must be properly

grounded. Operation with non-certified computers and cables may cause inter-

ference to other devices as well as the Fireface UFX II.

Unauthorized servicing/repair voids warranty. Only use accessories

specified by the manufacturer.

Read the manual completely. It includes all information necessary

to use and operate this device.

Produktspecifikationer

Varumärke:	RME
Kategori:	hi-fi system
Modell:	Fireface UFX II
Vikt:	3000 g
Bredd:	440 mm
Djup:	210 mm
Höjd:	44 mm
MIDI in:	Ja
MIDI ut:	Ja
USB-version:	2.0
Ljudutgång:	30
S/PDIF-ingång:	Ja
Antal analoga ingångar:	12
Inbyggd mikrofonförförstärkare:	Ja
Antal förförstärkare:	4
Produktens färg:	Grå
Antal USB-portar:	1
Formfaktor:	Rackmonterad
Strömförbrukning (vanlig):	25 W
AC-inspänning:	100-240 V
Växelström Frekvens:	50 - 60 hz
Strömkälla:	AC
Digital optisk utgång för ljud:	2
Ljudanslutning:	30
Digital audio optisk, ingående:	3
XLR-input:	1
Digitalt ljud optisk utgångstyp:	S/PDIF
Digitalt ljud optisk ingångstyp:	ADAT, S/PDIF
Word Clock-kontakt:	BNC
Världsklocka, ingående:	Ja
Världsklocka, utgående:	Ja
