Sida 1/56

Instruction Manual

Manuel d’Instructions

Bedienungsanleitung

INDEX

RECOMMENDATIONS AND SUGGESTIONS ..................................................................................................................... 4

CHARACTERISTICS ............................................................................................................................................................. 7

INSTALLATION ...................................................................................................................................................................... 9

USE ...................................................................................................................................................................................... 13

MAINTENANCE ................................................................................................................................................................... 14

SOMMAIRE

CONSEILS ET SUGGESTIONS .......................................................................................................................................... 16

CARACTERISTIQUES ......................................................................................................................................................... 19

INSTALLATION .................................................................................................................................................................... 21

UTILISATION ....................................................................................................................................................................... 25

ENTRETIEN ......................................................................................................................................................................... 26

INHALTSVERZEICHNIS

EMPFEHLUNGEN UND HINWEISE ................................................................................................................................... 28

CHARAKTERISTIKEN ......................................................................................................................................................... 31

MONTAGE ........................................................................................................................................................................... 33

BEDIENUNG ........................................................................................................................................................................ 37

WARTUNG ........................................................................................................................................................................... 38

RECOMMENDATIONS AND SUGGESTIONS

The Instructions for Use apply to several versions of this appliance.

Accordingly, you may find descriptions of individual features that do not

apply to your specific appliance.

INSTALLATION

•

The manufacturer will not be held liable for any damages resulting from

incorrect or improper installation.

• The minimum safety distance between the cooker top

and the extractor hood is 650 mm (some models can

be installed at a lower height, please refer to the

paragraphs on working dimensions and installation).

• Check that the mains voltage corresponds to that

indicated on the rating plate fixed to the inside of the

hood.

• For Class I appliances, check that the domestic

power supply guarantees adequate earthing.

Connect the extractor to the exhaust flue through a pipe of minimum

diameter 120 mm. The route of the flue must be as short as possible.

• Do not connect the extractor hood to exhaust ducts carrying combustion

fumes (boilers, fireplaces, etc.).

• If the extractor is used in conjunction with non-

electrical appliances (e.g. gas burning

appliances), a sufficient degree of aeration must

be guaranteed in the room in order to prevent the

backflow of exhaust gas. The kitchen must have

an opening communicating directly with the open

air in order to guarantee the entry of clean air.

When the cooker hood is used in conjunction with

appliances supplied with energy other than electric, the negative pressure in

the room must not exceed 0,04 mbar to prevent fumes being drawn back

into the room by the cooker hood.

• In the event of damage to the power cable, it must be replaced by the

manufacturer or by the technical service department, in order to prevent any

risks.

2°

Produktspecifikationer

Varumärke:	Roblin
Kategori:	Fläktkåpa
Modell:	Creatix 800
Bredd:	800 mm
Djup:	475 mm
Höjd:	- mm
Årlig energiförbrukning:	68 kWh
Motoreffekt:	270 W
Motor ingår:	Ja
Antal motorer:	1
Ljudnivå (låg hastighet):	45 dB
Antal lampor:	1 lampor
Höjd (min):	360 mm
Antal filter:	2 styck
Antal hastigheter:	3
Modell:	Väggmonterad
Produktens färg:	Stainless steel, White
Kontrolltyp:	Sensor
Tryck (Pa):	550
Fettfilter typ:	Metall
Höjd (max.):	650 mm
Lamptyp:	LED
Ljudnivå Lc IEC:	62 dB
Typ av fläkt:	Frånluft/recirkulerande
Maximal flödeskapacitet:	710 m³/h
Intensiv hastighet:	Ja
Evakueringsanslutning diameter:	150 mm
Energiklass, flödesdynamik:	B
Energiklass, belysning:	D
Energiklass, fettfiltrering:	G
Ljudnivå (hög hastighet):	60 dB
Ljudnivå (medelhög hastighet):	53 dB
