Sida 1/2

11/02 Printed in China MAN-4437-A

WARRANTY INFORMATION

Connecting Punch

Rockford Corporation

546 South Rockford Drive

Tempe, AZ 85281 USA

USA, (480) 967-3565

Europe, Fax (49) 4207-8101250

Japan, Fax (81) 559-79-1265

CPPI150

CPPI300

CPPI300HW

Installation &

OPERAtion Manual

Rockford Fosgate offers a limited warranty with the following terms:

• Length of Warranty

One year parts and labor warranty.

Requires proof of purchase.

• What is Covered

This warranty applies only to Rockford Fosgate products sold to

consumers by Authorized Rockford Fosgate Dealers in the United

States of America or its possessions. Product purchased by

consumers from an Authorized Rockford Fosgate Dealer in another

country are covered only by that country’s Distributor and not by

Rockford Fosgate.

• Who is Covered

This warranty covers only the original purchaser of Rockford Fosgate

product purchased from an Authorized Rockford Fosgate Dealer in the

United States. In order to receive service, the purchaser must provide

Rockford Fosgate with a copy of the receipt stating the customer

name, dealer name, product purchased and date of purchase.

Products found to be defective during the warranty period will be

repaired or replaced (with a product deemed to be equivalent) at

Rockford Fosgate’s discretion.

• What is Not Covered

1. Damage caused by accident, abuse, improper operations, water,

theft

2. Any cost or expense related to the removal or reinstallation of

product

3. Service performed by anyone other than Rockford Fosgate or an

Authorized Rockford Fosgate Service Center

4. Any product which has had the serial number defaced, altered,

or removed

5. Subsequent damage to other components

6. Any product purchased outside the U.S.

7. Any product not purchased from an Authorized Rockford Fosgate

Dealer

• Limit on Implied Warranties

Any implied warranties including warranties of fitness for use and

merchantability are limited in duration to the period of the express

warranty set forth above. Some states do not allow limitations on the

length of an implied warranty, so this limitation may not apply. No

person is authorized to assume for Rockford Fosgate any other

liability in connection with the sale of the product.

• How to Obtain Service

Please call 1-800-669-9899 for Rockford Fosgate Customer Service.

You must obtain an RA# (Return Authorization number) to return

any product to Rockford Fosgate. You are responsible for shipment

of product to Rockford Fosgate. Always include Proof of Purchase.

Mark RA# on outside of shipping carton.

INTRODUCTION

Thank you for purchasing the Rockford Fosgate

Connecting Punch Power Inverter.

The Connecting Punch Power Inverters allow you to

power a variety of AC voltage devices from your

car, truck, boat or RV. Power 110 volt AC power

devices such as notebook computers, video game

consoles, and TVs directly from a 12 volt DC power

supply.

Please read, understand and follow all instructions

before connecting the Connecting Punch Power

Inverter. If, after reading your manual, you still have

questions regarding this product, we recommend

that you see your Rockford Fosgate dealer. If you

need further assistance, you can call us direct at

1-800-669-9899.

Model CPPI150

Output Connection 1 North American Standard

Receptacle

Output Voltage Approx. 110 Volts AC RMS 60Hz

Output Current 1.36 Amps RMS

Output Waveform Modified Rectangular Wave

Input Voltage Range 10.6 to 15.5 Volts DC

Low Voltage Alarm Voltage drops below 10.6 Volts DC

Low Voltage Shutdown Voltage drops below 9.6 Volts DC

No Load Input Current 0.3 Amps

Input Fuse 20 Amp AGU

Input Cable Hard Wired Lighter Plug

Additional Protection Overload, Over Voltage, Over Temp

Dimensions Length: 5.6" (142.2mm)

Width: 4.1" (104.1mm)

Height: 1.85" (47.0mm)

Model CPPI300

Output Connection 2 North American Standard

Receptacles

Output Voltage Approx. 110 Volts AC RMS 60Hz

Output Current 2.73 Amps RMS

Output Waveform Modified Rectangular Wave

Input Voltage Range 10.6 to 15.5 Volts DC

Low Voltage Alarm Voltage drops below 10.6 Volts DC

Low Voltage Shutdown Voltage drops below 9.6 Volts DC

No Load Input Current 0.3 Amps

Input Fuse 40 Amp AGU

Input Cable Lighter Plug and Battery Clip Adapter

Additional Protection Overload, Over Voltage, Over Temp

Dimensions Length: 7.5" (190.5mm)

Width: 4.1" (104.1mm)

Height: 1.85" (47.0mm)

Model CPPI300HW

Output Connection 2 North American Standard

Receptacles

Output Voltage Approx. 110 Volts AC RMS 60Hz

Output Current 2.73 Amps RMS

Output Waveform Modified Rectangular Wave

Input Voltage Range 10.6 to 15.5 Volts DC

Low Voltage Alarm Voltage drops below 10.6 Volts DC

Low Voltage Shutdown Voltage drops below 9.6 Volts DC

No Load Input Current 0.3 Amps

Input Fuse 40 Amp AGU

Input Cable Lighter Plug and Battery

Hard Wire Kit

Additional Protection Overload, Over Voltage, Over Temp

Dimensions Length: 7.5" (190.5mm)

Width: 4.1" (104.1mm)

Height: 1.85" (47.0mm)

SPECIFICATIONS

150 watt or 300 watt

12 volt DC to 110 volt AC

Power Inverter
