Sida 1/4
R300-10
R300-12
Installation
Reference
Sheet
10” 300 Watt Powered Subwoofer
12” 300 Watt Powered Subwoofer
Features
Specications
Specications subject to change without notice.
R300-10 R300-12
General Features
• Optimized“closed-loop”design
• PrecisionconstructedMDFenclosurefor
superiorrigidityanddampening
• Remotebasslevelcontrolincluded
Woofer Features
• 10”Highoutputwoofer(R300-10)
• 12”Highoutputwoofer(R300-12)
(applicationspecic/optimized)
Amplier Features
• 300WattRMSClassDtopology
• High-efciency,lowcurrentdesign
• Thermalandovervoltageprotection
• Built-inadjustable45HzbassboostEQ
• Intelligentautoturnon/offfunction
• RobustPower/Groundconnections
• Adjustable12db/Octavelowpasscrossover
• Separatelowlevelandspeakerlevelinputs
(harnessincluded)
• 0˚/180˚phaseswitch
System Specications
FrequencyResponse.................................28Hz-90Hz
PowerRating(RMS/MAX).....................300W/600W
EnclosureType......................................2ndOrderSealed
R300-10Enclosure............................ 36.8Liters(1.3cuft)
R300-10Dimensions(HxWxD).....13.3”x18.38”x9.37”
R300-10NetWeight..........................21.9Lbs.(9.93Kg)
R300-12Enclosure............................. 56Liters(2.0cuft.)
R300-12Dimensions(HxWxD)...14.96”x20.35”x11.50”
R300-12NetWeight.........................25.4Lbs.(11.52Kg)
Replacement Parts
Hi-LevelInputHarness.........................1130-55119-01
Woofer Specications ...... R300-10 ....R300-12
Fs............................................................ 36Hz.............. 33Hz
Re...........................................................0.36Ω............ 0.42Ω
SPL(dB-1W/1M).............................84.5dB............84.5dB
Amplier Specications
InputSensitivity...................................... 100mV-3VRMS
InputImpedance..............................................20kΩ
12dB/octaveCrossover.......................... 35Hz-150Hz
BassBoost........................................0dBto+12dB@45Hz
THD.................................................................. <1.0%
S/NRatio..........................................................88.2dB
FuseRating....................................................30AATC
PowerInput.............................................Upto10AWG
Topology..................................................... BTLClassD
POW
PROT
GAIN
X-0VER
BASS
BOOST
MIN
MAX
35Hz
150Hz 0dB 12dB
30A
30A
30A
30A
30A
PHASE
180°
0°
PHASE
180°
0°
-40
+5
-35
-30
-25
-20
-15
-10
-5
+0
d
B
r
20 50030 40 50 60 70 80 90 100 200 300 400
Hz
-10
+20
-7. 5
-5
-2. 5
+0
+2. 5
+5
+7. 5
+10
+12. 5
+15
+17. 5
d
B
r
20 20030 40 50 60 70 80 90 1 00
Hz
LOW INPUT
HI-LEVEL INPUT
AUTO TURN ON NOTES
Requires 4mV signal
Nécessite 4mV signal
Benötigt 4mV Signal
Richiede 4mV segnale
Requiere 4mV señal
Needs 6V DC on factory speaker wires
Besoins 6V DC, le fils de l'usine haut-parleur
Needs 6V DC am Werk Lautsprecherkabel
6V DC, il bisogno di cavi dei diffusori di fabbrica
Necesidades de 6V CC en fábrica de cables de los altavoces
Use hi-level or Low-level input
Salut niveau ou à faible niveau d'entrée
Hallo-Level-oder Low-Level-Eingang
Hi-livello o di basso livello d'ingresso
Hi-nivel o de bajo nivel de entrada
AUDIO
DC OFFSET
REM
AUDIO
DC OFFSET
REM
AUDIO
DC OFFSET
REM
REM
