PS300-12
Installation
Reference
Sheet
12” 300 Watt Powered Subwoofer
Features
Specifications
General Features
• Flexible mounting options (hardware included)
• Quick disconnect Power and Input connections for
easy removal
Woofer Features
• 12" High output woofer
(application specific/optimized)
• Heavy-duty molded ABS slot-port enclosure
(internally damped)
• Bass reinforcing protective "Loading Plate"
(no grill needed)
Amplifier Features
• True 300 Watt RMS proprietary power amplifier
(closed loop optimized)
• Proprietary EQ/Compensation and fixed high order
low-pass filter
• Intelligent auto turn on/off function
• Optional remote bass level control (0dB to +20dB)
• Separate line level and speaker level inputs
(harness included)
• Custom extruded aluminum amplifer heat sink
• Thermal overload protection circuitry for maximum
safe run time
System Specifications
Frequency Response:................................................28 - 90Hz
P
o
w
er Rating (RMS/Max): ...............................300W / 600W
Enclosure Type:..............................................6th order vented
Enclosure Displacement:................26.231 Liters / 0.9 cu.ft.
Net Weight:............................................35.1 Lbs. / 15.921 Kg.
Dimensions (HxWxD):......................11.23”x21.18”x15.27”
Woofer Specifications
Fs (Hz): ..............................................................................36.3Hz
Re (Ohms):........................................................................1.60Ω
SPL (db - 1W/1M): .............................................................89dB
BL(T*M): ...................................................................................8.1
Xmax (mm):
......................................................................
8.5mm
Sd (cm2):
..................................................................................
530
Magnet (oz):.........................................................................56oz.
Voice Coil (in):.......................................................................2.0”
Amplifier Specifications
Input Sensitivity:..................................................150mV - 3.9V
Input Impedance:
...............................................................
20kΩ
Lo
w-Pass Filter
:
.....................................24dB/octave @ 90Hz
EQ:...............................................multi-pole cascadin circuitry
THD @ Rated Power:...................................................<0.10%
S/N Ratio: ..........................................................................95.8dB
Fuse Rating: ............................................................................40A
P
o
w
er
Wir
e Input: ...............................................up to 8AWG
LED
Indicators:...............................................Power / Thermal
Replacement Parts
Power Connector:........................(AP pack) 1130-55119-01
Hi-Le
v
el Input Harness:
...............
(AP pack) 1130-55119-01
Mounting Har
dwar
e:
........................................1130-55768-01
Subwoofer:.........................................................1465-55501-01
2
H
F
A
G
A
H
F
A
G
A
C
C
C
C
C
C
F
I
E
I
E
I
E
I
E
C
C
C
C
C
C
C
C
B
B
B
B
D
D
D
D
Factory Shipped
Fabrique équipe / Fabrik Schiff
Spedito Factory / Enviado Fábrica
Horizontal Mount
Montagne Horizontal / Horizontale Montage
Orizzontale Installare / Horizontal Instalación
Ver tical Mount
Montagne Ver ticale / Vertikalen Montage
Ver ticale Installare / Ver tical Instalación
1.7”
[ 43.18 mm ]
Bolt for Ve rtical Mount Bracket
[ M8 Hex or 5/16 Hex ]
Bolt for Bottom Cover
Without Mount Brackets
[ M8 Hex or 5/16 Hex ]
M6 Allen Key
Mounting Screw
[ M6 Hex or 15/64 Hex ]
Bolt for Bottom Cover
Horizontal Mount Bracket
[ M8 Hex or 5/16 Hex ]
M8 Allen Key
Standoff for Bottom Cover
Ver tical Mount Bracket
Standoff for To p Cover
Ver tical Mount Bracket
Bolt for Top Cover
Without Mount Brackets
[ M8 Hex or 5/16 Hex ]
2.76”
[ 70 mm ]
1.77”
[ 45 mm ]
1.34”
[ 34 mm ]
2.56”
[ 65 mm ]
1.77”
[ 45 mm ]
5.51”
[ 140 mm ]
0.24”
[ 6 mm ]
0.55”
[ 14 mm ]
Ø
0.57
”
[ 1
4.5
mm
]
Ø
0.5
7”
[ 1
4.5
mm
]
0.79”
[ 20 mm ]
0.157”
[ 4 mm ]
2.05”
[ 52 mm ]
x4
A
x4
B
x1
x1
x8
C
x4
x4
D
I
x2
H
x4
E
x2 x2
F
G
1.89”
[ 48 mm ]
3.03”
[ 77.03 mm ]
10.96”
[ 278.30 mm ]
8.27”
[ 210 mm ]
Ver tical Mount Bracket
Horizontal Mount Bracket
0.72”
[ 18.30 mm ]
2.48”
[ 63.09 mm ]
1.73”
[ 44 mm ]
2.24”
[ 56.80 mm ]
Hardware / Matériel / Wehrmaterial / Ferramenta / Ferretería
Configuration / Configurer / Konfigurieren / Configurazione / Configuración
