Sida 1/12

05/2009 B.M.

05/2009 E.R.

1230-55855-01

Printed in China

Serial Number: Date of Purchase:

Installation & Operation

Installation et fonctionnement

Instalación y funcionamiento

Einbau und Betrieb

Installazione e funzionamento

Component Systems

T152-S – 5.25˝

T1652-S – 6.5˝

T1T-S – Tweeter System

Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:

Length of Warranty

Speakers – 1 Year. Any Factory Refurbished Product – 90 days (receipt required)

What is Covered

This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate

Dealers in the United States of America or its possessions. Product purchased by consumers from an

Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor and

not by Rockford Corporation.

Who is Covered

This war

ranty co

ers onl

y the original pur

chaser of Rockford product purchased from an Authorized

Rockf

d F

osgate Dealer in the United States.

In or

der to receive service, the purchaser must provide

Rockf

d with a cop

y of the r

eceipt stating the customer name

, dealer name, product purchased and date of

pur

chase

oducts f

ound to be defective during the warranty period will be repaired or replaced

(with a pr

oduct deemed to be equivalent) at Rockf

d's discr

etion.

What is Not Covered

1. Damage caused by accident, abuse, improper operations, water, theft, shipping

2.Any cost or expense related to the removal or reinstallation of product

3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center

4.Any product which has had the serial number defaced, altered, or removed

5. Subsequent damage to other components

6.Any product purchased outside the U.S.

7.Any product not purchased from an Authorized Rockford Fosgate Dealer

Limit on Implied Warranties

Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the

period of the express warranty set forth above.Some states do not allow limitations on the length of an implied

warranty, so this limitation may not apply.No person is authorized to assume for Rockford Fosgate any other

liability in connection with the sale of the product.

w to Obtain Ser

vice

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further

assistance, call 1-800-669-9899 for Rockford Customer Service.You must obtain an RA# (Return

Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment

of product to Rockford.

arr

anty

This product meets the current EU warranty requirements, see your Authorized dealer for details.

Designed and Engineered by Rockford Fosgate,Tempe,AZ. USA.

Rockford Fosgate and the Rockford Fosgate logo are either

registered trademarks or trademarks of Rockford Corporation.

LIMITED WARRANTY ST

TEMENT

Rockford Fosgate

Rockford Corporation

600 South Rockford Drive

Tempe,Arizona 85281 U.S.A.

In U.S.A., (480) 967-3565 - Customer Service 1-800-669-9899

www

ockfordfosgate.com

Before beginning any installation, follow these simple rules:

1. Be sure to carefully read and understand the instructions before attempting to

install these speakers.

2. For safety, disconnect the negative lead from the battery prior to beginning the

installation.

3. For easier assembly, we suggest you run all wires prior to mounting your speakers

in place.

4. Use high quality connectors for a reliable installation and to minimize signal or

power loss.

Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines,

brake or hydraulic lines, vacuum lines or electrical wiring when working on any

vehicle. If installation in a boat, take care not to cut or drill through the main hull.

6. Never run wires underneath the vehicle. Running the wires inside the vehicle or

hull ar

ea pr

ovides the best protection.

7. Avoid running wires over or through sharp edges. Use rubber or plastic

grommets to protect any wires routed through metal, especially the firewall.

Determine wher

e the speakers will be mounted. Ensure an area large enough for

the speak

er to mount evenly. Be sure that the mounting location is deep enough

for the speaker to fit; if mounting in a door, operate all functions (windows, locks,

etc

.) thr

ough their entir

e operating range to ensur

e ther

e is no obstruction.

2. Refer to the specification chart to determine the proper diameter hole to cut

for your speaker model.The template provided also gives the proper cutout size.

Mark the locations f

or the mounting scr

ws.

Drill the holes with a 1/8" bit.

4. Feed the speaker wires through the cutout and connect to the speaker terminals.

Be sure to observe proper polarity when connecting the wires.The speaker's

positiv

e terminal is indicated with a "+".

5. On models with slotted holes, fit the speaker into the cutout and install the

screws in the slots at the top and bottom.This will allow you to rotate the speak-

er to match the r

emaining mounting holes.

When aligned, tighten the screws.

6. Tighten the screws until the speaker is snug in place to prevent rattling. Do not

over tighten the screws.

NOTE: If needed, use the adapter plate provided to mount the speaker.

See Adapter Plate Templates at the end of this manual.

SAFETY

CARTON CONTENTS

CAUTION: Before installation, disconnect the battery

negative (-) terminal to prevent damage

to the unit, fire and/or possible injury.

• (1) Set T1 Series Speakers with Tweeters and 2-Way Crossover

or (1) Set T1 Series Tweeters with HP Crossover

• (1) Set of grilles/trim rings

• (2) Sets of tweeter trim rings:

(1 set of polished aluminum)

(1 set of brushed aluminum)

• Tweeter Mounting Hardware with Surface, Angle, and Flush Mounts

• (1) Set Adapter Plates: T152-S (5”x7”/6”x9”), T162-S (5”x7”/6”x9”)

INSTALLATION CONSIDERATIONS

MOUNTING

snap!

Removing tabs for

some installations

Break off

mou

nting tab.

Use pl

iers to break off

plastic tab.

Cutout

Hole

Position to

Align Holes

Example of standard

door installation

T152S Only

Use tip of a small flat

screwdriver to remove tweeter

Example of Discreet Dual Clamp (DDC™)

Tweeter Mounting (Flush Mount)

Panel

PRACTICE SAFE SOUND™

Continuous exposure to sound pressure levels over 100dB may

cause permanent hearing loss. High powered auto sound systems

may produce sound pressure levels well over 130dB. Use common

sense and practice saf

e sound.

Produktspecifikationer

Varumärke:	Rockford Fosgate
Kategori:	högtalare
Modell:	T1652-S
Vikt:	4260 g
Impedans:	4 Ω
Känslighet:	89 dB
Toppeffekt:	200 W
Märkeffekt:	100 W
diskanthögtalare:	Ja
Frekvensområde:	55 - 22000 hz
Separata komponenter:	Ja
Högtalartyp:	2-vägs
Disktanthögtalare diameter:	25 mm
Övergångsfrekvens:	3000 hz
Mellandrivenhet diameter:	165 mm
Passiv övergång:	Ja
