Thank you for purchasing the RAdjustable Unossbar for

Tripod Speaker Stands. Pleasehese instr carefully bee. Make

sure all parts are included. If an are mplease contact our te

help line at 1-646-758-0144, Mthrouy, 9am to 5pm EST. Als

can check out our informationaon YouTps://youtu.be/wIMpfZ

or search Rockville RCS52.

RCS52

OWNER’S MNAL

RockvillePro.com

© 2017 ROCKVILLE // The information presented is subject to change and or improvement without notice.

Begin by mounting the RCS52 crossbar to any lighting stand or speaker tripod with standard 35mm mounting.

Simply loosen the mounting lock knob (fig. A) and slide the bar onto the top of the speaker pole (fig. B). Be sure

to tighten the lock knob (fig. C) so as to ensure that the bar is securely mounted.

ASSEMBLING THE CROSSBAR

The RCS52 has a maximum load weight of 6nd can hol six lights.

attach lights simply remove the horizontal lock nd mount theas prescribed

by the manufacturer. To attach more than four lights, 2 additionauded lock

nuts. Be sure to check the load limit on your stand to ensun support the weight

of the crossbar and the lights.

EXTENDING THE CROSSBAR

ATTACHING LIGHTS

• RCS52 Adjustable Universal Lighting Crossbar Stand

• Adjustable from 5ft to 7.5ft

• Bolts attached to Bar for easy attachments and assembly

• Steel tube telescopic horizontal T-bar can support up to 6 cans

• Can be assembled on lighting stands with standard 35 mm mounting

• Black Finish

• Minimum length: 5 feet (60˝)

• Maximum length: 7.5 feet (90˝)

• Unit Weight: 6.2 lbs.

• Shipping Weight: 7.0 lbs.

• Product dimensions: 59˝ x 5.9˝ x 1.4˝

• Packing dimensions: 60˝ x 6.7˝ x 1.8˝

• Tube dimensions: 1.2˝ x 1.2˝

• Maximum loading weight: 66 lbs.

• Lower tube: 1.4˝ (inner radius)

FEATURES/SPECIFICATIONS

The RCS52 can extend from 5 feet to 7.5 feet. To extend the crossbar, loosen and remove the horizontal lock

knobs (fig. D). Pull the end of the extension bar until hole 1 of the extension aligns with hole 2 of the exterior

bar (fig. E). Insert one set of lock knobs to secure the extension firmly in place (fig. F).

1 pc.

2 pcs.

fig. A

fig. B

fig. C

fig. D

fig. E

fig. F

HOLE 1

HOLE 1

HOLE 2

HOLE 2
