Acclaim™ 5 Series OutBack

Outdoor Loudspeaker

Installation Manual

Russound Acclaim OutBack Loudspeaker Installation Manual

Rev. 1

INTRODUCTION

Introduction

Thank you for selecting the Russound Acclaim 5 Series Outdoor Speakers.

Like all Russound speakers, they combine acoustic technology with durability

and will provide years of musical enjoyment.

The Acclaim 5 Series line provides solutions for background music and

dedicated music listening. They combine premium acoustic materials with

advanced drivers to deliver exceptional performance in every application.

A key benet to using these speakers is the high-eciency design, which

means less amplication power is needed - less power does not mean quiet!

The speaker comes with two installation options: a free-standing base and

a bracket mount. The base attaches to one end of the speaker and provides

a stable vertical placement option for shelf or table. The bracket mount

accommodates at surface and corner locations, plus the bracket accepts

U-bolts for attaching the speaker to a pole. Once the bracket is installed, the

speaker slips into slots on the bracket so you don’t have to hold the speaker

in place while securing it. The bracket and speaker have knurls for secure

alignment to the desired angle.

Designed and built to withstand the rigors of outdoor environments, the 5

Series outdoor speakers will provide years of trouble-free service. They work

in a wide range of temperatures and be unaected by extremes of humidity.

A corrosion-resistant aluminum grille and bracket coupled with the speaker’s

rugged environmental design assures durability in any kind of weather. Sealed

enclosure oers greater durability against the environment's rigors.

3Rev. 1

Russound Acclaim OutBack Loudspeaker Installation Manual

Speaker

Mounting bracket

End cap Mounting knob

Grille

Bookshelf foot option

Speaker assembly

The bracket has screw slots to accommodate both wall and pole installation

options. The speaker sits in the speaker bracket's "C" openings and is pivoted

into place and secured with the mounting knobs. End caps provide a cosmetic

covering over the bracket's attach points.

An included bookshelf foot option mounts in place of the bracket for an

attractive upright shelf installation for a speaker pair.

SPEAKER ASSEMBLY

Painting the speaker

The speaker mounting bracket, enclosure, end caps, and grille can be

painted. If you paint the speaker, do not get paint on the speaker drivers. Also

be sure to minimize paint buildup so as not to clog the grille holes.

1. Gently pull o the speaker grille, making sure not to distort it.

2. Mask the speaker terminals and bae (the area on the front of the

enclosure that houses the drivers).

3. Paint the bracket, enclosure, end caps, and grille separately. Spraying is

ideal, but if you can’t spray the paint, a roller with a short or medium nap

will work better than a brush. Apply one or two light coats.

4. While the paint is still wet, clear any clogged holes in the grille with bursts

of compressed air.

5. After the paint has thoroughly dried, remove the masking. Gently press

the grille into place on the speaker, using even pressure around the edge.
