Sida 1/2
www.salus-controls.com
SALUS Controls is a member of the Computime Group
Maintaining a policy of continuous product development SALUS Controls plc reserve the right to change specification,
design and materials of products listed in this brochure without prior notice.
Issue Date: August 2017
V01
For PDF Installation guide please go to
www.salus-manuals.com
Head Office:
SALUS Controls plc
SALUS House
Dodworth Business Park South,
Whinby Road, Dodworth,
Barnsley S75 3SP, UK.
T: +44 (0) 1226 323961
E: sales@salus-tech.com
LG+5V - RF Boiler Control
Press the “SYNC“ button for 3 seconds
until LED starts ashing
The LG+5V is ready to be paired
with your compatible SALUS device.
6. Push t boiler control into housing.
7. Power up the boiler and check the
correct operation. Note: Once paired please close the boiler control panel
Installation Pairing the LG + 5V
5. Connect the electrical plug.
3 Sec
Introduction
The LG+5V boiler module 868MHz is a receiver with 5V DC to control ON/
OFF of Boiler or other heat system via the RF signal transmitted from the
thermostat.
Product Compliance
This product complies with the essential requirements and other
relevant provisions of Directives (RED) 2014/53/EU and 2011/65/EU.
The full text of the EU Declaration of Conformity is available at the
following internet address: www.salus-controls.com.
Safety Information
Use in accordance with the regulations. Indoor use only. Keep your
device completely dry. Disconnect your device before cleaning it with
a dry cloth.
868MHz-868.8MHz; <13dBm
Terminal connections
The LG+V5 is compatible with the following SALUS products
RT310TX
RT510TX iT500TR
RT310iTX
ERT20TX
Compatibility
Terminal Identier Description
1 DC + DC power supply (+)
2 DC - DC power supply (-)
3 COM Common input
4 NO Normal Open
5 NC Normal Closed
Installation
Switch Position
1
1 2 3
2
3
The boiler receiver is o.
AUTO. RX will automatically
receive the RF signal from your
compatible SALUS device and
controls relay output.
Manual mode - Manual Override
(Note this mode will run your boiler continuously)
1. Ensure boiler is isolated and switched o.
2. Pull down control panel cover.
3. Remove existing mechanical timer and unscrew from plate.
4. Reverse the procedure to install the RXBC5V.
Note: When removing blanking plate also remove visible
thermostat link plug do not remove any internal link.
i
