Real Time DVR

user manual

imagine the possibilities

SHR-6040

SHR-6042

English

Real Time DVR user manual

AB82-01484A Rev-02 TK

SHR-6042_Eng-Cover.indd 1 2009-06-12 오후 6:05:18

key features of your DVR

Your purchased digital video recorder (DVR) compresses a 4-channel camera input into an MPEG4 video; also, it provides the

functions that record to the HDD in real-time and play the content by compressing the 4-channel audio input with G.723.

Also through the network, it transmits video and audio to an external device in real-time and allows monitoring the video and

audio through a PC from a remote location.



4-Channel Composite Input Connectors



NTSC/PAL Video Source Compatible



The D1 size (NTSC : 704x480 / PAL : 704x576) of video can be saved at a speed of 90ips(NTSC)/75ips(PAL) (Image Per

Second).



4-Channel Loop Through Video Connectors



Supports the overwrite mode of HDD.



Large capacity HDD backup by using the USB 2.0 interface



Backup by using the USB 2.0 memory and DVD-RW



Record, play, and simultaneous video and audio transmissions to the Windows Network Viewer (Net I).



Possible to record and play the 4-channel audio



Various saving modes (Continuous, Motion, Alarm In and Schedule)



Alarm interface (input: 4, output: 2)



Remote monitoring function by using the Windows Network Viewer (Net I)

WHAT’S INCLUDED WITH YOUR DVR

When you have purchased this product, please take off the packing and place this device on a ﬂat ﬂoor or put it down on the

place desired for use. And then, check whether all the following components are included in the box. If a component is found

to be missing, please contact the place that you have purchased this product.

Remote control unit (RCU)

Adaptor

2 EA of AAA batteries

User’s Manual

1 power cable

Special 4 screws

Software CD

(including the PDF manual)

SHR-6042_Eng_01.indd 2 2009-06-05 오후 3:46:38

safety regulations

Please be sure to keep the following in mind for the right use of the product to prevent proprietary risk or damage.



Do not use multiple plugs at once.

This may cause abnormal heat generation or ﬁre



Do not put a vase, ﬂowerpot, cup, cosmetics, medicine, or vessel with water around you.

This may cause ﬁre.



Do not bend the power cord forcibly nor put a heavy material on it.

This may cause ﬁre.



Do not touch the power plug with wet hands.

This may cause electric shock.



Insert the power plug ﬁrmly enough not to shake.

This imperfect connection may cause ﬁre.



Keep the product off humidity, dust, or soot.

This may cause ﬁre or electric shock.



Do not put metals (coin, hair pin, metal piece, etc.) or inﬂammable materials (match, paper, etc.) in the

ventilation hole.

This may cause ﬁre.



Keep the surrounding temperature between 0°C to 40°C and keep the product off humidity.

This may cause breakdown.



Secure sufﬁcient ventilation.

This may cause abnormal operation due to high temperature.



Keep the product off direct ray of light or heat from the heating device.

This may cause ﬁre.



Do not disassemble, repair, or remodel the product.

This may cause ﬁre, electric shock, or injury due to abnormal operation.



Do not pull out the power cord.

This may destroy the power cord, eventually, cause ﬁre or electric shock.



Plug out in the event of thunder or lightning.



This may cause ﬁre.



Keep your children off the battery after you take it out of the product. They tend

to swallow it unconsciously.

If your children swallow it, please see the doctor immediately.



Install the product at a safe place or attach the product to the wall or ceiling with a stand ﬁrmly enough

not to fall to the ground.

This may injure people.

SHR-6042_Eng.indb 3 2009-06-05 오전 11:23:25
