Sida 1/40

Factory reset

If you wish to completely reset your radio to its initial state this may

be performed by following this procedure.

1. Press the Tuning+/- buttons on the main menu (Press the Back

button if necessary), until it shows <Setting>.

2. Press the Back button.

3. Press the Tuning+/- buttons until it shows <Factory Reset>.

And then press the Select button.

4. The display will show “Are you sure?” Press the Tuning+/- buttons to

select “YES”. And then press the Select button. Now the radio is

factory reset.

Upgrade firmware

From time to time, new software features for your radio may be

developed. For example, a new audio decoder may be added to allow

an alternative audio format to be supported. You radio has therefore

been designed to allow its internal software to be upgraded using your

Internet connection.

Upgrading the software will remove all network settings, radio station

presets and alarm settings from your radio. Do not attempt this

procedure unless you have a good Internet connection and a reliable

mains power supply. If you connect to your router using a Wi-Fi

connection, make sure that this is also reliable before proceeding.

The Upgrade Firmware option allows your radio to download new

internal software from the Reciva portal on the Internet. If there is

new software available, then the radio will ask whether you want to

download it or not. Selecting No or using the Back button will cancel

the operation.

1. On the main menu (press the Back button if necessary), Press the

Tuning+/- buttons until it shows < Setting >. And then press the

Select button.

2. Press the Tuning+/- buttons until it shows <Upgrade Firmware>,

and then press the Select button.

3. If there is a new software different from the software your

radio installed, you will be able to upgrade the software.

Or it will show “No upgrade available”.

A software upgrade may take several minutes.

IMPORTANT:

Do not switch off the power to the radio until the upgrade operation is

complete and the radio has restarted, otherwise the radio may become

permanently damaged.

Headphone socket

1. A 3.5mm Headphone Socket located on the rear of your radio is

provided for use with headphones. Inserting a plug automatically

mutes the internal loudspeaker.

IMPORTANT:

Excessive sound pressure from earphones and headphones can cause

hearing loss.

Line out socket (3.5mm Jack)

A 3.5mm Line Out socket located on the rear of your radio is provided

for connecting the audio signal to an external amplifier. Inserting an

audio cable into this socket will not mute the internal loudspeaker.

Set the volume control on the radio to minimum if desired.

Specifications

Power AC 100 ~ 240 volts, 50 ~ 60 Hz.

Connectivity Wired Ethernet Wi-Fi 10/100M bits/sec via RJ-45 802.11b

and 802.11g supported WEP and WPA encryption supported

Notice:

The changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

the equipment.

Produktspecifikationer

Varumärke:	Sangean
Kategori:	Radio
Modell:	RCR-8WF
Vikt:	1043.5 g
Ljudformat som stöds:	MP3, WMA
Inbyggda högtalare:	Ja
Bakgrundsbelysning:	Ja
Produktens färg:	Svart, silver
Snooze funktion:	Ja
Skärmtyp:	LCD
Uteffekt (RMS):	0.7 W
Produktstorlek (BxDxH):	193 x 165.1 x 76.2 mm
Likströmsingång:	Ja
Linje ut:	Ja
Vilolägestimer:	Ja
Antalet förinställda stationer:	10
Typ av radio:	Internet
FM band:	87.5 - 108 MHz
