THANK YOU FOR CHOOSING SANUS

VIELEN DANK, DASS SIE SANUS GEWÄHLT HABEN

MERCI D'AVOIR CHOISI SANUS

GRACIAS POR ELEGIR SANUS

VLL

Instruction Manual

WE’RE HERE TO HELP

Our install experts are

standing by to help.

Get it right the ﬁrst time.

HeightFinder™ shows you

where to drill.

Check it out at:

SANUS.com/2567

Want to watch a video that

shows how easy this DIY

project will be?

Watch it now at:

SANUS.com/495

Recommended placement

Call us at:

US: +1 (800) 359-5520

EMEA: +31 (0) 495 580 852

UK: +44 (0) 800 056 2853

Texto en español, página 20

Texte français page 22

Deutscher Text Seiten 24

Nederlandse tekst op pagina 26

Svensk text sida 28

Русский текст: стр. 30

中文文本，第32页

日本のテキスト、34ペジ

IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE

—

Perfect!

Yes

—

This mount is NOT compatible. Visit MountFinder.Sanus.com or call US: +1 (800) 359-5520;

EMEA: +31 (0) 495 580 852; UK: +44 (0) 800-056-2853) to find a compatible mount.

Please read through these instructions completely to be sure you’re comfortable with this easy install process.

Also check your TV owner’s manual to see if there are any special requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,

contact Customer Service.

Do you have

all the tools

needed?

Before getting started, let’s make sure this mount is perfect for you!

What is your

wall made of?

Drywall with

steel studs?

Unsure?

Drywall with

wood studs?

Solid concrete or

concrete block?

CAUTION: Avoid potential personal injuries and property damage!

● This product includes directions and hardware for use with wood stud, solid concrete and concrete block walls – DO NOT install into

drywall alone. For information on how to use this product with steel stud walls contact Customer Service and ask about the SSMK1 steel

stud mounting kit.

● The wall must be capable of supporting five times the weight of the TV and mount combined.

● Do not use this product for any purpose not explicitly specified by manufacturer.

● Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.

Perfect! Perfect!

Ready to

begin?

Steel stud kit (#SSMK1) required

79.3 kg

(175 lbs)

Does your TV weigh

more than 79.3 kg

(175 lbs) including

accessories?

Wood Stud Install

Concrete Install

Pencil Screwdriver

Tape

Measure

7/32 in.

(5.5 mm)

Wood

Drill Bit

Electric Drill

Hammer

1/2 in.

(13 mm)

Socket

Wrench

Drill Bit

3/8 in.

(10 mm)

Concrete

Call Customer Service: US: +1 (800) 359-5520

(EMEA: +31 (0) 495 580 852;UK: +44 (0) 800-056-2853)

Awl

Stud

Finder

Level

Produktspecifikationer

Varumärke:	Sanus
Kategori:	Wandstöd
Modell:	VLL5
Vikt:	3910 g
Bredd:	762 mm
Höjd:	475 mm
Maximal skärmstorlek:	90 "
Minsta skärmstorlek:	42 "
Maxvikt:	79.38 kg
Justerbart djup:	Nej
Produktens färg:	Svart
Monteringssätt:	Vägg
Höjdjustering:	Nej
Antal displayer som stöds:	1
Monteringsgränssnitt kompatibilitet (min):	200 x 200 mm
Monteringsgränssnitt kompatibilitet (max):	600 x 400 mm
Färgdjup (max):	23 mm
Antal per pack:	1 par
