Sida 1/16

VSTV

INSTRUCTION MANUAL

We’ll Make It Stress-Free

If you have any questions along the way, just give us a call.

1-800-359-5520. We’re ready to help!

Before getting started, let’s make sure this mount is perfect for you!

IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE– SAVE THESE INSTRUCTIONS

Please read through these instructions completely to be sure you’re comfortable with this easy install process. Also check your TV owner’s manual to see

if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation,

assembly or use of this product, contact Customer Service at 1-800-359-5520.

WARNING: Avoid potential personal injuries and property damage!

●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.

●Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the weight of the TV

(including any accessories) does not exceed 60 lbs (27.2 kg). Use with heavier televisions may result in instability causing tip over resulting in death or serious injury!

●Use this mounting system only for its intended use as described in these instructions. Do not use attachments not recommended by the manufacturer.

●Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may

encourage a child to climb on the furnishing and as a result the furnishing may tip over onto the child.

●Relocating audio and/or video equipment to furniture not speciﬁ cally designed to support audio and/or video equipment may result in death or serious injury

due to the furnishing collapsing or overturning onto a child.

NOTE: The VSTV1 has no user serviceable parts.

60 lbs.

(27.2 kg)

TV Weight Limit

(including accessories)

DO NOT EXCEED

Tools Needed Level Screwdriver

Visit sanus.com or call 1-800-359-5520

to ﬁ nd a compatible mount.

Dimensions in. [mm]

7.08 in.

[180.00 mm]

4.72 in.

[120.00 mm]

3.97 in.

[101.00 mm]

26.45 in.

[672.00 mm]

8.03 in.

[203.99 mm]

15.98 in.

[406.00 mm]

23.93 in.

[608.00 mm]

3.38 in.

[86.00 mm]

10.43 in.

[265.00 mm]

21.87 in.

[555.70 mm]

17.21 in.

[437.29 mm]

18.00 in.

[457.00 mm]

15.75 in.

[400.00 mm]

7.87 in.

[200.00 mm]

23.62 in.

[600.00 mm]

16.92 in.

[430.00 mm]

12 in.

[305.00 mm]
