VSTV2-B2

Swivel TV Base

INSTRUCTION MANUAL

Our install experts are

standing by to help.

Call us at:

US: +1 (800) 359-5520

EMEA: +31 (0) 495 580 852

UK: +44 (0) 800 056 2853

Want to watch a video that

shows how easy this DIY

project will be?

Watch it now at:

SANUS.com/3093

WE’RE HERE TO HELP

Texto en español, página 16

Deutscher Text Seiten 20 Svensk text sida 24

中文文字说明请参见第 28 页

Texte français page 18 Nederlandse tekst op pagina 22

Русский текст: стр. 30

日本語は 26 ページ

Level

Screwdriver

125 lbs.

(56.6 kg)

TV Weight Limit

(including accessories)

DO NOT EXCEED

Tools

Needed

If your TV (plus accessories)

weighs MORE, this mount is

NOT compatible.

Visit SANUS.com or call

customer service to find a

compatible mount.

IMPORTANT SAFETY INSTRUCTIONS

– PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS

Please read through these instructions completely to be sure you’re comfortable with this easy install process. Also check your TV owner’s manual to see if there are any special

requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service.

CAUTION: Avoid potential personal injuries and property damage!

CAUTION: Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.

WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the weight of the

display (including accessories) does not exceed 125 lbs (56.6 kg). Use with heavier televisions may result in instability causing tip over resulting in death or serious injury!

WARNING: Use this mounting system only for its intended use as described in these instructions. Do not use attachments not recommended by the manufacturer.

WARNING: Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may

encourage a child to climb on the furnishing and as a result the furnishing may tip over onto the child.

WARNING: Relocating audio and/or video equipment to furniture not specifically designed to support audio and/or video equipment may result in death or serious injury due

to the furnishing collapsing or overturning onto a child.

NOTE: This product supports TVs from 40 in. to 86 in. (diagonal).

NOTE: This product has no user serviceable parts.

Dimensions

3.94in

100mm

MIN VESA

15.75in

400mm

MAX VESA

23.62in

600mm

MAX VESA

3.94in

100mm

MIN VESA

35deg

11.40in

289.5mm

5.37in

136.5mm

16.77in

426mm

22.28in

566mm

4deg

TILT

25.00in

635.1mm

35.57in

903.5mm

24.80in

630mm

5deg ROLL

0.98in

25mm

HEIGHT

ADJUST

7.87in

200mm

TOTAL

HEIGHT

ADJUSTMENT

18.44in

468.5mm

35.57in

903.5mm

10.57in

268.5mm

27.70in

703.5mm

TV INTERFACE

HEIGHT ADJUSTMENT

TOP VIEW - SWIVEL

3-D

SIDE VIEW - EXTENDED

SIDE VIEW - RETRACTED

SIDE VIEW - TILT

FULLY ASSEMBLED MOUNT

Produktspecifikationer

Varumärke:	Sanus
Kategori:	TV-skåp
Modell:	VSTV2-B2
Vikt:	11400 g
Bredd:	565.9 mm
Djup:	426 mm
Höjd:	703.6 mm
Förpackningens bredd:	704.1 mm
Förbättrad kabelhantering:	Ja
Maximal skärmstorlek:	86 "
Förpackningsvolym:	38658.4 cm ^
Minsta skärmstorlek:	40 "
Maxvikt:	56.7 kg
Produktens färg:	Svart
VESA-fäste:	Ja
Låddjup:	475 mm
Vikt inkl. förpackning:	13072.75 g
Enkel installation:	Ja
Monteringssätt:	Bord
Gränsssnitt för panelmontering:	100 x 100,600 x 400 mm
Höjdjustering:	Ja
Monteringsgränssnitt kompatibilitet (min):	100 x 100 mm
Monteringsgränssnitt kompatibilitet (max):	600 x 400 mm
Vridningsvinkel:	70 °
Färgdjup (max):	426 mm
