1
WSEPM21
INSTRUCTION MANUAL
2.5 lbs.
(1.1 kg)
Speaker Weight Limit:
DO NOT EXCEED
Tools Needed
Wood Stud Install
Concrete Install
Awl
Pencil
Stud Finder
Phillips
Screwdriver
Drill Bit
Electric
Drill
Hammer
Drill Bit
¼ in.
(6.5 mm)
Masonry
⅛ in.
(3 mm)
Wood
¼ in.
(6.5 mm)
Drywall Install
Hammer
Drill Bit
6901-602684 00
: CAUTIONAvoid potential personal injuries and property damage!
•
Check your speaker owner’s manual to see if there are any special requirements for mounting your speaker.
•
Do not use this product for any purpose not explicitly specified by manufacturer.
•
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
•
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service.
SANUS.com
(North America)
US: 1-800-359-5520
•
Parts and Hardware
WARNING: DO NOT FEED TO CHILDREN! This product contains small items that could be a choking hazard if swallowed. Keep these items
away from young children!
: NOTENot all hardware included will be used.
: NOTEQuantities shown are for one mount.
a
b
Parts and Hardware for STEP 1
Wall Plate Screw
Bracket
Cap
Speaker Screw
Assembly Screw
Wall
Anchor
#10 x 1¾ in.
1/4-20 x 1/2 in.
10-24 x 5/8 in.
Parts and Hardware for STEP 2
02 x2
01
06 x1
05 x1
08 x1
07 x1
DSRZJA
ES
Tilt & Swivel Wall Mount
for Amazon Echo (4th Gen)
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ENTIRE MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS
Please read through these instructions completely to be sure you're comfortable with this easy install process.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service.
SANUS.com
(UK & EMEA)
UK: 0800-056-2853
•
: +31 (0) 495 580 852 EMEA
•
We’re here to help!
Our install experts are standing
by to help.
Call us at:
US: 1-800-359-55200800 056 2853 UK: ●
EMEA: +31 (0) 495 580 852
www.SANUS.com
Produktspecifikationer
| Varumärke: | Sanus |
| Kategori: | Smarth hem |
| Modell: | WSEPM21 |
| Bredd: | 72.6 mm |
| Placering: | Vägg |
| Antal per låda: | 1 styck |
| Produktens färg: | Vit |
| Lutningsjustering: | Ja |
| Höjd (max.): | 115.6 mm |
| Vridningsvinkel: | 150 ° |
