WSSAWM1
SOUNDBAR WALL MOUNT
DESIGNED FOR
Sonos® Arc™
INSTRUCTION MANUAL
WE’RE HERE TO HELP
If you have any questions along the way, our US-based
install experts are standing by to help.
Or, chat at: US: SANUS.com/chatSP
Call us at: US: 800-359-5520
UK: 0800 056 2853
EMEA: +31 (0) 495 580 852
This mount is designed
to support Sonos® Arc™
soundbar and works with
SANUS and other TV
mount brands.
2
YOU’D LOVE THIS KIT!
Complete your installation by hiding your cables with the
In-Wall Power Kit for Soundbar + Mounted TV
Check out SANUS.com, SONOS.com, or Amazon.com!
• Works perfectly with the
Sonos® Arc™ Wall Mount
• Hides all cabling behind the wall
• Can power multiple devices
• Safe and easy to install with no
electrician needed
BEFORE
IN-WALL
POWER KIT
FOR SOUNDBAR + MOUNTED TV
Model WSIWPSB1-W1
Available in the U.S. only
3
14 lbs.
(6.4 kg)
CAUTION: To avoid potential personal injuries and property damage:
• This soundbar mount is only designed for use with the Sonos
® Arc™ speaker.
• Please read through these instructions completely to be sure you’re comfortable with this easy install process.
• Do not use this product for any purpose not explicitly specified by manufacturer.
• Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
• If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,
contact Customer Service.
Before getting started, let’s make sure this product is perfect for you!
IMPORTANT SAFETY INSTRUCTIONS. READ ENTIRE MANUAL PRIOR TO USE. SAVE THESE INSTRUCTIONS
23.98in
609mm
9.65in
245mm
1.38in
35mm
2.00in
50.8mm
28.45in
722.6mm
11.02in
280mm
26.16in
664.4mm
25.21in
640.4mm
5.05in
128.4mm
1.08in
27.4mm
SIMULATED 55"
FLAT SCREEN TV
WALL IS ON RIGHT
WALL IS ON TOP
WALL IS ON TOP
WALL IS ON RIGHT
TV INTERFACE
WALL PLATE
TOP VIEW - TV MOUNTED
3-D
3-D
SIDE VIEW
TOP VIEW
FULLY ASSEMBLED MOUNT
DIMENSIONS IN. [MM]
Weight Limit
DO NOT EXCEED
Wall
Construction
Concrete block/
Solid concrete
Dry wall Wood stud
Drill Bit
Tools Needed
Drywall
Install
Pencil Level Electric Drill HammerDrill Bit
13/32 in.
(10 mm)
Concrete
Concrete
Install
13/32 in.
(10 mm)
Wood Stud
Install
Drill Bit
1/8 in.
(3 mm)
Wood
