AUDIO INTERFACE WITH DUAL
LAVALIER MICROPHONE KIT
For iOS devices, Android devices and Computers User Ma nual
1 General Introduction
Smart V2M is an all-in-one stereo solution for
recording hands-free audio to your smartphones
and PC. It requires no battery and could output
real stereo sound to your smart devices. SmartV2M
includes two clip-on omnidirectional condenser
lavalier microphones in 3M (9.84ft.) and 5M (16.4
ft.), a two-channel audio interface, and three
signal transmission cables.
Two 1/8" (3.5mm) mic inputs allows you to
record audio to the left and right channel, the
volume of each channel could be adjusted
separately. You could select mono or stereo
output mode according to different recording
application. The headphone jack provides
real-time and playback audio monitoring.
2 Product Structure
Smart V2M
⑤
⑥
⑨
①
③
②
⑧
⑥
⑨
⑦
④
⑩ ⑪ ⑫ ⑬ ⑭ ⑮
① MIC 1 input: 1/8" (3.5mm) TRS screw lock
microphone input.
② MIC 2 input: 1/8" (3.5mm) TRS screw lock
microphone input.
③ LED indicator: indicates the recording status
and input level control set-up.
④ Audio output jack: one Micro USB 2.0 stereo
audio output.
⑤ Mono/Stereo switch: select mono or stereo
output modes.
⑥ "+""-" input level control buttons: adjust the
recording input level.
⑦ 1/8" (3.5mm) stereo TRS headphone jack:
connect headphones to monitor the audio.
⑧ REC/PLAY monitor switch: select real-time
monitoring or playback monitoring mode.
⑨ Grip holder to mount the hook & loop touch
fastener strap.
⑩ Hook & loop touch fastener strap.
⑪ A 1M Micro USB to USB Type-C cable for
connecting the Smart V2M to Android devices
with USB Type-C jack.
⑫ A 1M Micro USB to Lightning cable for
connecting the Smart V2M to Apple iOS
devices.
⑬ A 20cm Micro USB to standard USB cable for
connecting the Smart V2M to a computer.
⑭ A 3M clip-on omnidirectional condenser
lavalier microphone.
⑮ A 5M clip-on omnidirectional condenser
lavalier microphone.
3 Setup Guide
① Connect the supplied lavalier microphones to
the Mic1 and/or Mic2 input.
For a secure connection, please make sure to
rotate clockwise and lock the connector.
② Connect the SmartV2M to a smartphone or a
PC by the supplied corresponding cable.
③ The LED indicator will turn to blue once open
a recording application.
④ Set Mono/Stereo switch: select mono or
stereo output mode.
The mono mode is for one mono microphone
recording. It can send the mono audio signal
to each channel and mix together to output
stereo audio signal.
The stereo mode is for two channels record-
ing, it records the microphones on two
separate channels of audio.
⑤ Clip the lavalier microphone to your shirt near
the collar.
⑥ Plug headphones into the headphone input
to monitor the audio. Select REC for real-time
monitoring or select PLAY for playback
monitoring.
The LED indicator will turn to green while
playback.
4 Specifications 5 Compatibility
iPhone, iPad and iPod Touch
Android devices with USB Type-C jack
Mac and PC Computers with USB-A jack
6 Packing List
Smart V2M main unit
Two lavalier microphones
Three output cables
Hook & loop touch fastener strap
Storage bag
User manual
Warranty card
⑦ Adjust the input level.
MIC1: Long press the "-" button, the LED is
blinking in green and solid in blue. Short
press the "+""-" buttons to adjust the input
level of MIC1, long press again to save
settings and exit.
MIC2: Long press the "+" button, the LED is
blinking in blue and solid in green. Short
press the "+""-" buttons to adjust the input
level of MIC2, long press again to save
settings and exit.
MIC1&MIC2: Short press the “+”/ “-”, the input
level of both channels will be adjusted
simultaneously.
⑧ We suggest you could do a test recording
and playback the audio to see if it is accept-
able.
Inputs
Frequency Response
Gain
Sampling Frequency
Bitrate
20Hz-20kHz
0-30dBu
44.1kHz / 48kHz
16Bit / 24Bit
Power Requirements
Supplied by iOS Devices / Android Devices / PC
Micro USB to Apple MFi Certified Lightning
Micro USB to USB Type-C
Micro USB to USB-A
1 x MIC1 1/8"(3.5mm) jack for mono mics
1 x MIC2 1/8"(3.5mm) jack for mono mics
Output Cables
Lavalier Mic
Cable Length
3M (9.84 ft.)
5M (16.40 ft.)
Weight 250g (about 8.82oz.)
Dimension 65x65x25.5mm
