Sida 1/96
POWER SUPPLY
INSTALLATION GUIDE
1. Remove your old PSU (power supply unit)
1.1. Disconnect your AC power cord
from the wall socket and the back of
the power supply.
1.2. Disconnect
all DC cable connectors.
1.3. Remove all 4 mounting screws.
1.4. Remove your old PSU.
WARNING! IMPORTANT SAFETY INFORMATION
• NEVER, under any circumstances, open the power supply
unit. High voltage inside. WARRANTY IS VOID once the
cover is removed.
• DO NOT insert any object into the fan grill or the ventilation
area of the power supply unit.
• DO NOT place any object in front of the fan or the
ventilation area of the power supply unit that may obstruct
or restrict airflow.
• USE ONLY the Seasonic modular cables provided with the
power supply unit.
• Keep the power supply unit in a dry environment, away
from humidity.
• The power supply unit is for integration into a computer
system and not intended for external or outdoor usage.
Warning!
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interfer ence received,
including interference that may cause undesired operation.
• Product: Switching Power Supply
Model name: Please refer to the rating label on the product.
• Contact: www.seasonic.com/contact-us
BUMWHGUD3AW


Produktspecifikationer

Varumärke: Seasonic
Kategori: ej kategoriserat
Modell: Vertex GX-850
Bredd: 150 mm
Djup: 160 mm
Höjd: 86 mm
Certifiering: cTUVus, TUV, CB, CCC, BSMI, EAC, CE, Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Medeltid mellan fel (MTBF): 150000 h
Kombinerad effekt (-12V): 3.6 W
CPU-strömkabelns längd: 650 mm
Garantiperiod: 10 År
Produktens färg: Svart
Förpackningstyp: Låda
Effekt skyddsfunktioner: Over current, Over power, Over voltage, Short circuit, Under voltage
Temperatur vid drift: 0 - 50 ° C
Hållbarhetscertifiering: CE, REACH, RoHS
AC-inspänning: 100 - 240 V
Fläktdiameter: 135 mm
Kabel inkluderad: AC, CPU, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA
Växelström Frekvens: 50 - 60 hz
På / av-knapp: Ja
ATX-version: 3.0
Ingående ström: 11 - 5.5 A
Antal fläktar: 1 fläkt/-ar
Ändamål: PC
Total effekt: 850 W
Kylning typ: Aktiv
Periferiska (Molex) strömkontakter (4-pin): 1
Antalet SATA strömkontakter: 4
Kombinerad effekt (+3,3 V): 125 W
Kombinerad effekt (+12 V): 840 W
Kombinerad effekt (+5 V): 125 W
Max utström (+3,3 V): 20 A
Max utström (+12 V): 70 A
Max utström (+5 V): 20 A
Max utström (-12V): 0.3 A
Max utström (+5 VSB): 3 A
Strömförsörjningsenhet formfaktor: ATX
Moderkort strömkontakt: 20+4 pin ATX
Längd, moderkortets strömförsörjningskabel: 610 mm
SATA-nätkabelns längd: 950 mm
CPU strömkontakt (4 +4 pin): Ja
Typ av kablage: Helt modulär
80 plus-certifiering: 80 PLUS Gold
Kullagertyp: FDB
Buntband inkluderat: Ja
Kombinerad effekt (+5 VSB): 15 W
Tillbehörsnätkabelns (Molex) längd: 690 mm
ATX strömkontakt (20 4 stift): Ja
CPU P4-kontakt (4-stifts): 2
