PRECAUTION ON USING THE COMPASS

■

ROTATING COMPASS BEZEL (RING)

(using with the 24-hour hand to indicate directions)

●

Please use the compass in places where the sun is visible or its location is known.

●

Before using the compass, it is necessary to set the 24-hour hand to the current time of your area.

●

The compass is so designed to provide only a rough indication of directions, and should not be used

where accuracy is critical.

●

If daylight saving time (summer time) is in effect in your area, be sure to set your watch one hour behind

the current time before using the rotating compass.

How to use the compass bezel (ring)

1 Set “N (North) ” on the rotating compass bezel (ring) to the 12 o’clock marker. The direction marks on

the bezel (ring) are set as follows;

3 o’clock position: E (East)

6 o’clock position: S (South)

9 o’clock position: W (West)

2 While keeping the dial level, point the 24-hour hand in the direction of the sun. The direction marks

indicate the corresponding directions.

NSYRCR07

8-2011

[In the Southern Hemisphere]

1 Set “S (South) ” on the rotating compass bezel (ring) to the 24-hour hand.

2 While keeping the dial level, point the 12 o’clock marker in the direction of the sun. The direction

marks indicate the corresponding directions.

[In the Northern Hemisphere]

[In the Southern Hemisphere]

[In the Northern Hemisphere]

East

West

North

South

North

WestEast

12 o'clock marker 12 o'clock marker

PRECAUTION ON USING THE COMPASS

■

ROTATING COMPASS BEZEL (RING)

(using with the hour hand to indicate directions)

●

Please use the compass in places where the sun is visible or its location is known.

●

The compass is so designed to provide only a rough indication of directions, and should not be used

where accuracy is critical.

●

If daylight saving time (summer time) is in effect in your area, be sure to set your watch one hour behind

the current time before using the rotating compass.

How to use the compass bezel (ring)

(ENGLISH)

2 Set “N (North)” on the rotating compass bezel (ring) to the middle point of the arc between the 12 o’clock

marker and the time scale indicated by the hour hand.

* In the AM period, set the rotating compass bezel (ring) to the middle point of the arc to the left of the

12 o’clock marker. In the PM period, set the bezel (ring) to the middle point of the arc to the right of

the 12 o’clock marker.

3 “N (North),” “S (South),” “E (East),” and “W (West)” on the rotating compass bezel (ring) indicate the

directions of “north,” “south,” ”east,” and “west,” respectively.

[In the Northern Hemisphere]

South

While keeping the dial level, point the hour hand in the direction of the sun.

Set “S (South)” on the rotating compass bezel (ring) to the middle point of the arc between the 12

o’clock marker and the time scale indicated by the hour hand.

* In the AM period, set the rotating compass bezel (ring) to the middle point of the arc to the left of

the 12 o’clock marker. In the PM period, set the bezel (ring) to the middle point of the arc to the right

of the 12 o’clock marker.

3 “N (North),” “S (South),” “E (East),” and “W (West)” on the rotating compass bezel (ring) indicate the

directions of “north,” “south,” ”east,” and “west,” respectively.

North

12 o’clock marker 12 o’clock marker

[In the Southern Hemisphere]

[ In the Northern Hemisphere]

West

East

West

[In the Southern Hemisphere]

While keeping the dial level, point the 12 o’clock marker in the direction of the sun. *The above ﬁgures are examples when the compass is used in the AM period.
