HDA 200 Audiometric Headphone

Closed dynamic headphones designed for extended high frequency testing.

Features

♦

Excellent passive attenuation (based on Peltor

TM

Ear Defenders)

♦Very high quality sound reproduction

♦Convenient single sided cable

♦Padded headband and additional adjustable/removable cushions for increased comfort

♦Soft, replaceable circumaural ear pads

♦Color coded ear cups, right (red) left (blue)

Technical Data

Frequency response20 to 20,000 Hz< >

PTB calibratedsee table

Transducer principledynamic, closed

Nominal impedance40 Ohm

Characterisitic SPL100 dB at 1 kHz, 1 mW

Max permanentload500 mW

Couplincircumauragl

Caliper pressure10 N

Weight (with cable)330 g

Cable approx. 3 m,single-sided, open-ended

Connectioyellonw+ L

black– L

red+ R

white– R

StandardLPaeMaum SPLSPssivxim

frequencies (dB 20Paattenuation(<10 min. @µ)

(Hz) @ .5 Vrms(dB)5 V RMS)

Sennheiser Electronic Corporation One Enterprise Drive PO Box 987, Old Lyme, C 0637T1

Tel:860-434-9190Fax: 860-434-1759Web site: www.sennheiserusa.com

HDA200 is PTB approved.Physikalisch-Technische

Bundesanstalt, Braunschweig, Germany. PTB is equivalent to

the National Bureau of Standards.

125112.514.3132 3±

250113.015.9132 3±

500112.022.5132 3±

7501.0-131 311±

1,000108.528.6129 3±

2,000104.0124 -± 3

3,000104.0124 332.0±

4,000104.045.7124 3±

5,000106.5-127 ± 3

6,000107.5-125 ± 3

8,000105.543.8125 5±

9,000105.0-123 ± 5

10,000102.5-122 ± 5

11,200102.0-123 ± 5

12,500103.0-118 5±

14,00098.5-119 5±

16,000100.0-120 ± 5

•All measurements are done on a calibrated coupler

B&K 4153 (artificial ear) with the standard cone

YJ0304 above the adapter plate, type DB 0843.

•The pressure of the headband shall be 10N ± 1N.

•The RMS input voltage to the headphone is 0.5 V.

•The measurements are done with steady state sine

wave signals.

•The output impedance of the signal source shall be

<1 Ohm.

•Climatic conditions:

Temrature20peT=

º C

HumiditH=50%reyl

Atmospheric pressureP=approx. 100kPa

All data are influenced by temperature, humidity and static pressure.

HDA 200 Frequency Response Test Conditions
