Sida 1/2
www.SereneLifeHome.com
Commercial Storage Container Bin
Safety & Security Essential Storage Box
(37 Gal. Capacity)
Installation Instructions
Please read the instructions carefully before assembly and use. Clear the space for
assembly and lay out all parts based on the Parts List. Ensure that all pieces are present.
Lay out the bottom, the left (A) and
right (B) side plate Insert left (A) and
right (B) side panel into the bottom
card slot that corresponds to the
position, as shown in Figure 1.
Add two screws each side to secure in
the side plates.
1 2
A
A
C
D
B
B
Y
Y
X
X
Figure 1
Press the former (D) and the rear (C)
plate into left and right plate respectively
according to the Y direction, then insert
into bottom slots in the X direction, as
shown in Figure 3.
Reinforce front plate and rear plate
respectively with three screws and
one screw for each of the four corner
posts, as shown in Figure 4.
3
4
Figure 2
Figure 3 Figure 4
www.SereneLifeHome.com
Steps to set the code of the cipher lock
1. The initial code is .0000
2. Switch the lever from Point B to Point A,
after conrm about the initial code.
3. Set your own code
4. Switch the lever from Point A to Point B, after the code is set.
5. Please memorize the code that you set and follow step 2, step 3 and step 4 to set a new code.
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: support@pyleusa.com
Install the top cover to the back cover.
Set it approximately at the angle of 60°,
then insert the damper shaft following B
direction.
Set password to complete Assembly.
5 6
Note: For the safety purpose, this box does not reserve
any position for outer unlock device in its structural
design and is not easy to dismantle after assembly.
Please pay full attention to each steps of code setting,
make sure the 4 digits lock codes set is exactly in parallel
line, then put the code set lever back to " " position, do B
not forget your set codes to avoid any inconvenience.
A
B
B
60
