ACT Flood 100 RGBW
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Product code: 34041
USER MANUAL
ENGLISH
V1
1
ACT Flood 100 RGBW
Product code: 34041
Preface
Thank you for purchasing this Showtec product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
● Safety instructions
● Intended and non-intended use of the device
● Installation and operation of the device
● Maintenance procedures
● Troubleshooting
● Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2022 Showtec. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at service@highlite.com.
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.
2
ACT Flood 100 RGBW
Product code: 34041
Table of contents
1. Introduction .......................................................................................................................................................... 4
Before Using the Product .................................................................................................................................. 4
Intended Use ....................................................................................................................................................... 4
Product Lifespan ................................................................................................................................................. 4
LEDs Lifespan ....................................................................................................................................................... 4
Text Conventions ................................................................................................................................................ 5
Symbols and Signal Words ................................................................................................................................ 5
Symbols on the Information Label .................................................................................................................. 5
2. Safety .................................................................................................................................................................... 6
Warnings and Safety Instructions .................................................................................................................... 6
Requirements for the User ................................................................................................................................. 8
3. Description of the Device ................................................................................................................................... 9
Front View ............................................................................................................................................................ 9
Back View ............................................................................................................................................................ 9
Barndoor ............................................................................................................................................................10
Product Specifications ....................................................................................................................................11
Dimensions .........................................................................................................................................................12
4. Installation .......................................................................................................................................................... 12
Safety Instructions for Installation ..................................................................................................................12
Personal Protective Equipment .....................................................................................................................12
Installation Site Requirements ........................................................................................................................12
Rigging ...............................................................................................................................................................13
Angle Adjustment ............................................................................................................................................13
Barndoor Installation ........................................................................................................................................14
Connecting to Power Supply .........................................................................................................................15
Power Linking of Multiple Devices .................................................................................................................15
5. Setup ................................................................................................................................................................... 16
Warnings and Precautions .............................................................................................................................16
Stand-alone Setup ...........................................................................................................................................16
DMX Connection ..............................................................................................................................................16
DMX-512 Protocol .......................................................................................................................................16
DMX Cables .................................................................................................................................................17
DMX Linking ..................................................................................................................................................18
DMX Addressing ..........................................................................................................................................18
6. Operation ........................................................................................................................................................... 19
Safety Instructions for Operation ...................................................................................................................19
Control Modes ..................................................................................................................................................19
Control Panel ....................................................................................................................................................20
Start-up ...............................................................................................................................................................20
Menu Overview ................................................................................................................................................21
Main Menu Options .........................................................................................................................................23
DMX Functions .............................................................................................................................................23
DMX Address .......................................................................................................................................23
DMX Channel Mode ..........................................................................................................................23
DMX Fail ................................................................................................................................................24
View DMX Value .................................................................................................................................24
Manual Settings ..........................................................................................................................................24
Mode ....................................................................................................................................................25
Show Chase ........................................................................................................................................25
Fixture Settings .............................................................................................................................................26
Display Settings............................................................................................................................................26
Fixture Test ....................................................................................................................................................27
Manually Defined ...............................................................................................................................27
4
ACT Flood 100 RGBW
Product code: 34041
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
● Showtec ACT Flood 100 RGBW
● Schuko to pro-power cable (1,5 m)
● Barndoor
● User manual
Fig. 01
Intended Use
This device is intended for professional use as a theater wash effect. It is suitable only for indoor
installation. This device is not suitable for households and for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Product Lifespan
This device is not designed for permanent operation. Disconnect the device from the electrical power
supply when the device is not in operation. This will reduce the wear and will improve the device’s
lifespan.
LEDs Lifespan
The light output of the LEDs gradually decreases over time (lumen depreciation). High operating
temperatures contribute to this process. You can extend the lifespan of the LEDs by providing adequate
ventilation and operating the LEDs at the lowest possible brightness.
5
ACT Flood 100 RGBW
Product code: 34041
Text Conventions
Throughout the user manual the following text conventions are used:
● Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons”
● References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “turn the adjustment handle (05)”
● 0–255: Defines a range of values
● Notes: Note: (in bold lettering) is followed by useful information or tips
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Electrical hazard
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the mounting
bracket.
The information label contains the following symbols:
This device is designed for indoor use.
This device shall not be treated as household waste.
Read and follow the instructions in the user manual before installing, operating or servicing
the device.
This device falls under IEC protection class I.
6
ACT Flood 100 RGBW
Product code: 34041
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
● Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage (> 120 V DC) may be present.
● Do not open the device or remove any covers.
● Do not operate the device if the covers or the housing are open. Before operation, check if the
housing is firmly closed and all screws are tightly fastened.
● Disconnect the device from electrical power supply before service and maintenance, and when the
device is not in use.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection class I.
● Make sure that the device is electrically connected to ground (earth). Connect the device only to a
socket-outlet with ground (earth) connection.
● Do not cover the ground (earth) connection.
● Do not bypass the thermostatic switch or fuses.
● For replacement use fuses of the same type and rating only.
● Do not let the power cable come into contact with other cables. Handle the power cable and all
connections with the mains with caution.
● Do not modify, bend, mechanically strain, put pressure on, pull or heat up the power cable.
● Make sure that the power cable is not crimped or damaged. Examine the power cable periodically
for any defects.
● Do not immerse the device in water or other liquids. Do not install the device in a location where
flooding may occur.
● Do not use the device during thunderstorms. Disconnect the device from the electrical power supply
immediately.
7
ACT Flood 100 RGBW
Product code: 34041
WARNING
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at
strobe lights.
Attention
Power supply
● Before connecting the device to the power supply, make sure that the current, voltage and
frequency match the input voltage, current and frequency specified on the information label on the
device.
● Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the
required power consumption of the device.
Attention
General safety
● Do not insert objects into the air vents.
● Do not connect the device to a dimmer pack.
● Do not switch the device on and off in short intervals. This decreases the device’s life.
● Do not shake the device. Avoid brute force when installing or operating the device.
● Change the lens or the LEDs if they are visibly damaged to such an extent that their effectiveness is
impaired, for example by cracks or deep scratches. Contact your Highlite International dealer for
more information, as servicing can be performed only by instructed or skilled persons.
● If the device is dropped or struck, disconnect the device from the electrical power supply
immediately.
● If the device is exposed to extreme temperature variations (e.g. after transportation), do not switch it
on immediately. Let the device reach room temperature before switching it on, otherwise it may be
damaged by the formed condensation.
● If the device fails to work properly, discontinue the use immediately.
Attention
For professional use only
This device shall be used only for the purposes it is designed for.
This device is intended for professional use as a theater wash effect. Any incorrect use may lead to
hazardous situations and result in injuries and material damage.
● This device is not suitable for households and for general lighting.
● This device is not designed for permanent operation.
● This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.
8
ACT Flood 100 RGBW
Product code: 34041
Attention
Before each use, examine the device visually for any defects.
Make sure that:
● All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
● The safety devices are not damaged.
● There are no deformations on housings, fixations and installation points.
● The lens is not cracked or damaged.
● The power cables are not damaged and do not show any material fatigue.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Maintenance may be carried by ordinary persons.
Installation and service shall be carried out only by instructed or skilled persons. Contact your Highlite
International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the installation, service and maintenance of
this product, so that they can identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.
9
ACT Flood 100 RGBW
Product code: 34041
3. Description of the Device
The Showtec ACT Flood 100 RGBW is a compact, yet powerful floodlight for indoor installation in theatres
with an asymmetric high-grade reflector with a beam angle of 90° by 105°. The device is delivered with
an 8-leaf barndoor.
Front View
01) Mounting bracket
02) 2 x Adjustment handles
03) Lens
04) 3 x Color frame holders
05) Color frame clip
Fig. 02
Back View
06) Control panel: OLED display and
control buttons
07) 3-pin DMX signal connector OUT
08) Safety eye
09) Pro-power connector OUT 100–
240 V, 50/60 Hz (Gray)
10) Pro-power connector IN 100–240 V,
50/60 Hz (Blue)
11) Fuse T2 A/250 V AC
12) 3-pin DMX signal connector IN
13) Manual dimmer control
14) Preset colors control
Fig. 03
10
ACT Flood 100 RGBW
Product code: 34041
Barndoor
15) Safety eye (barndoor)
Fig. 04
12
ACT Flood 100 RGBW
Product code: 34041
Dimensions
Fig. 05
4. Installation
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
If trussing systems are used, installation must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning rigging and trussing.
Personal Protective Equipment
During installation and rigging wear personal protective equipment in compliance with the national and
site-specific regulations.
Installation Site Requirements
● The device can be used only indoors.
● The device can be mounted to a truss or another rigging structure in any orientation.
● The minimum distance to other objects must be bigger than 0,5 m.
● The maximum ambient temperature t
a
= 40 °C must never be exceeded.
● The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.
Produktspecifikationer
| Varumärke: | Showtec |
| Kategori: | Lättnad |
| Modell: | ACT Flood 100 RGBW |
Behöver du hjälp?
Om du behöver hjälp med Showtec ACT Flood 100 RGBW ställ en fråga nedan och andra användare kommer att svara dig
Lättnad Showtec Manualer
2 April 2025
31 Januari 2025
22 December 2024
22 December 2024
20 December 2024
20 December 2024
26 September 2024
26 September 2024
26 September 2024
26 September 2024
Lättnad Manualer
- Varytec
- Adviti
- ARRI
- Mr Safe
- Halo
- Astro
- Vimar
- NUVO
- Berger & Schröter
- SilverStone
- XQ-Lite
- Black Diamond
- Doughty
- Altman
- Envivo
Nyaste Lättnad Manualer
9 April 2025
9 April 2025
9 April 2025
8 April 2025
8 April 2025
8 April 2025
7 April 2025
5 April 2025
5 April 2025
5 April 2025
